API Delevan SDS130R - Manual

Actual Size
D
A
S
H
N
U
M
B
E
R
*
IN
D
U
C
TA
N
C
E
(µ
H
)
TE
S
T F
R
E
Q
U
E
N
C
Y
(M
H
z)
D
C
R
E
S
IS
TA
N
C
E
M
A
X
IM
U
M
(O
H
M
S
)
C
U
R
R
E
N
T R
AT
IN
G
M
A
X
IM
U
M
(m
A
)
TO
LE
R
A
N
C
E
SERIES
SDS130R
Surface Mount Shielded Power Choke
Physical Parameters
Inches Millimeters
A 0.500 ±0.008 12.7 ±0.2
B 0.398 ±0.008 10.1±0.2
C 0.118 Max. 3.0 Max.
D 0.094 ±0.008 2.4 ±0.2
E 0.087 ±0.008 2.2 ±0.2
F 0.303 ±0.015 7.7 ±0.4
G 0.287 Ref. 7.3 Ref.
H 0.118 Ref. 3.0 Ref.
I 0.110 Ref. 2.8 Ref.
Current rating at 25°C Ambient
40°C Max. Rise
Operating Temperature Range
-40°C to +85°C
Weight Maximum
0.85 grams
Marking For values lower than 10
μ
H the R indicates a
decimal point and the remaining digits indicate the
inductance in
μ
H. For values 10
μ
H and above, the first
two digits indicate the inductance in μ H and the third digit
indicates the number of trailing zeros where a zero
indicates that there are no trailing zeros.
Example: SDS130R-222N (2.2
μ
H)
2R2
Example: SDS130R-473M (47
μ
H)
470
Packaging
Tape & Reel (24mm): 13" reel
1000 pieces max.
P
o
w
er
In
d
u
ct
o
rs
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
SERIES SDS130 FERRITE CORE & SLEEVE
-222N
-302N
-392N
-472N
-682N
-103M
-123M
-153M
-183M
-223M
-273M
-333M
-393M
-473M
-563M
-683M
-823M
-104M
-124M
-154M
-184M
-224M
-274M
-334M
-394M
-474M
2.2
3.0
3.9
4.7
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
±30%
±30%
±30%
±30%
±30%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
100
100
100
100
100
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.045
0.062
0.070
0.078
0.100
0.145
0.185
0.20
0.27
0.30
0.40
0.45
0.56
0.65
0.68
0.80
1.20
1.40
1.52
1.80
2.20
2.70
3.10
3.60
4.60
5.10
3500
3000
2800
2500
2200
2000
1750
1500
1400
1300
1200
1100
950
800
750
700
650
600
550
500
450
400
350
300
250
200
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
1/2009
