API Delevan P1330 & P1330R User Manual
Series, Surface mount power inductors, Po w er i nd uc to rs

Actual Size
DA
SH
NU
MB
ER
*
IN
DU
CT
AN
CE
(µ
H)
±10
%
@
1 k
Hz
DC
R
ES
IST
AN
CE
MA
XIM
UM
(O
HM
S)
CU
RR
EN
T R
AT
IN
G
MA
XIM
UM
(m
A D
C)
IN
CR
EM
EN
TA
L
CU
RR
EN
T (m
A D
C)
SERIES
P1330R
P1330
Surface Mount Power Inductors
Physical Parameters
Inches Millimeters
A 0.300 to 0.325 7.62 to 8.26
B 0.105 to 0.125 2.67 to 3.18
C 0.125 to 0.145 3.18 to 3.68
D 0.020 Min. 0.508 Min.
E 0.040 to 0.060 1.02 to 1.52
F 0.190 (Ref. only) 4.83 (Ref. only)
G 0.070 (Ref. only) 1.78 (Ref. only)
Weight Max (Grams) 0.30
Operating Temperature Range –55°C to +125°C
Current Rating at 90°C Ambient 35°C Rise
Maximum Power Dissipation at 90°C 0.210 W
Inductance Measured at 1V with no DC current
Incremental Current The current at which the inductance
will be decreased by a maximum of 5% from its initial zero
DC value.
Marking API/SMD; inductance with units and tolerance
followed by a P; date code (YYWWL). Note: An R before
the date code indicates a RoHS component.
Example: P1330-104J
API/SMD
8.2uH±10%P
0719A
Packaging Tape & reel (16mm): 7" reel, 500 pieces max.;
13" reel, 2200 pieces max.
Made In the U.S.A.
Po
w
er I
nd
uc
to
rs
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
SERIES P1330 FERRITE CORE
-102K
-122K
-152K
-182K
-222K
-272K
-332K
-392K
-472K
-562K
-682K
-822K
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
-824K
-105K
1526
1400
1291
1180
1104
936
840
732
720
612
600
600
564
516
432
420
348
324
270
270
246
216
174
150
132
111
106
89
72
60
57
48
41
35
30
26
22
2780
2690
2030
1950
1690
1550
1460
1390
1330
1110
1080
1020
946
912
858
817
694
657
568
488
467
442
384
362
347
327
272
261
223
191
179
171
161
138
130
113
105
0.035
0.041
0.043
0.048
0.075
0.080
0.108
0.118
0.125
0.145
0.165
0.180
0.216
0.252
0.288
0.328
0.384
0.425
0.538
0.600
0.792
0.900
1.020
1.380
1.680
1.800
2.040
2.400
2.648
4.320
4.800
5.640
6.000
6.960
8.760
9.960
11.160
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Optional Tolerances: J = 5% H = 3% G = 2%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
1/2009
