Radial Toroidal Inductors
Military Specification MS21423 (Ref.)
Mechanical Configuration Units are radial leaded and
encapsulated in an epoxy molded package.
Physical Parameters
Inches Millimeters
A 0.200 to 0230 5.08 to 5.84
B 0.190 to 0.210 4.83 to 5.33
C 0.090 to 0.110 2.29 to 2.79
D 0.090 to 0.110 2.29 to 2.79
E 1.00 Min. 25.4 Min.
F 0.0185 to 0.0215 0.470 to 0.546
Operating Temperature –55°C to +125°C
Current Rating at 90°C Ambient 35°C Rise
Maximum Power Dissipation at 90°C 0.200 W
Note Inductance measured 0.25" from body.
Weight Max. (Grams) 0.5
* * Note Self Resonant Frequency (SRF) values above
250 MHz are calculated and for reference only.
Marking 4445; dash number with tolerance letter; Delevan
cage code (99800); date code (YYWWL). Note: An R after
4445 indicates a RoHS component.
Example: 4445-01M
4445
-01M
99800
0828A
Packaging Bulk only
Made in the U.S.A.
R
F I
nd
uc
to
rs
