ACL Cathode T50 Details/Specs - Manual (Page 3)

© 20
10 Ar
chit
ectur
al Cat
hode Lighting, Inc. Product
(1) For a 1 lamp standard ballast system see B100. For a 2 lamp high output ballast system see B200.
(2) For multiple selections place a comma after each selection.
Standard Output
Cold Cathode System
60mA
T50 DB
_ _ _ _ _ _
S01
(2)
DI - Dim
ND - Non Dim
S - Surface
Standard Color (s) Dim-able Mount Primary Environment
120V
277V -Special
Order
Note: For a variation (custom) of this product contact ACL to request a variation number and information. S P E C I F I C A T I O N C O D E :
DR - Dry
DP - Damp
WT - Wet (DB)
See Chart
(1) S01 S
date: April 6, 2010 file: T50details.pdf page: 3 of 3
Boot
1/2" Coupling w/
Internal Thread
1/2" Reducing
Washer
1/2”
2 3/4”
Tie Wire
Boot
Lamp Support
25mm Cathode Lamp
Double Feed Detail - Double Back (DB)
Plan
Double Feed Detail - DB
Elevation NTS
Intermediate Detail - DB
Plan NTS
NTS
Section Detail - DB
NTS
Boot Lamp Support
2”
3/8”
1/2" Coupling w/
Internal Thread
1/2" Reducing
Washer
1 7/8”
Inside Face
of Cove
GTO 15 Cable
in Sleeve
25mm Cathode Lamp Boot
3/8”
Architectural Cathode Lighting, Incorporated
ACL INC.
c a t h o d e l i g h t i n g . c o m
5 3 0 1 P a c i f i c B o u l e v a r d
Huntington Park California 90255 USA
Telephone 323.581.8800
Fax 323.581.7971
i n f o @ c a t h o d e l i g h t i n g . c o m
CA
TH
O
DE
T
50
A Fusion of the Art and Science of Light
DE
TA
IL
S
C A T H O D E T 5 0 P R O D U C T D E T A I L S :
T50 is a low material cost, energy efficient cold cathode
lighting system. When comparing the data it out performs LED.
•228 Lumens per foot (compared to 82 LED)
•54.65 Lumens per watt (compared to 21.57 LED)
•Approx. 4 - 5 watts per foot
•Over 30 bright colors (compared to 8 LED)
•Full Range Dimming
•50,000 Hour Lamp Life
T50 Specifications
60mA Secondary
(1) For 277V and HPF contact ACL.
(2) Use VA for computing loads. Use Watts for computing power consumption.
X
Y
Z
4.625”
17.625”
8.0”
Z
Y
X
Watts VA(2) AMPS Sec.V
292 540 4.5 9000
243 450 3.75 7500
162 300 2.5 5000
Project Name Linear Feet Date
DR 120V DI
