ACL Lineon Neon Details/Specs - Manual

Product
_ _ _ _ _ _ _
(1)
DI - Dim
ND - Non Dim
(3)
Standard Color Dim-able Secondary Finish Primary Environment
DR - Dry
DP - Damp
See Chart
(1) For multiple selections place a comma after each selection
(2) NPF - Normal Power Factor, HPF - High Power Factor, 277V may be a special order.
(3) Normal power factor when dimming, high power factor maybe available when non-dimming. Contact ACL.
NOTE: Watts per foot will vary. Contact ACL to compute actual load for each project.
S01 LN - Lineon
(NEON)
LN NA
WT - Wet
120V NPF
120V HPF
277V NPF
277V HPF
(2)
30 MA
60 MA
NA
L I N E O N • N E O N D E T A I L S :
date: November 2, 2008
sheet description: Lineon Neon Details
file: LNdetails.pdf
page: 1 of 1
DE
TA
IL
S
A Fusion of the Art and Science of Light
© 2005 Ar
chit
ectur
al Cat
hode Lighting, Inc.
LI
N
EO
N
N
EO
N
Architectural Cathode Lighting, Incorporated
ACL INC.
5 3 0 1 P a c i f i c B o u l e v a r d
Huntington Park California 90255 USA
Telephone 323.581.8800
Fax 323.581.7971
i n f o @ c a t h o d e l i g h t i n g . c o m
c a t h o d e l i g h t i n g . c o m
Boot
1/2" Coupling w/
Internal Thread
1/2" Reducing
Washer
1/2”
2 1/2”
Tie Wire
Boot
Lamp Support
15mm Neon Lamp
Double Feed Detail
Plan
Double Feed Detail
Elevation NTS
Intermediate Detail
Plan NTS
NTS
Section Detail
NTS
Boot
2”
3/8”
1/2" Coupling w/
Internal Thread
1/2" Reducing
Washer
1 7/8”
Inside Face
of Cove
GTO 15 Inside
Masters GTO Cable
Sleeving, Gray
Lamp
Lamp Support Boot
3/8”
Note: For a variation (custom) of this product contact ACL to request a variation number and information. S P E C I F I C A T I O N C O D E :
Project Name Linear Feet Date
