Appendix B – Pinout
Bosch LSU version (LTC 4.9)
LTC Connector A
LTCD Connector A and B
Bosch LSU 4.9 sensor connector
Mating connector: supplied on sensor
Pin No Wire Colour Description
1 Red Ip
2 Yellow Sensor 0 V
3 White Heater -
4 Grey Heater +
5 Green Ipr
6 Black Vs
Power/CAN Connector
DTM 4pin (M) (#68055)
Mating connector: DTM 4pin (F) (#68054)
Pin No Wire Colour Description
1 Black Battery -
2 Green CAN Lo
3 White CAN Hi
4 Red Battery +
