58 Appendices MoTeC
Wiring
Connector
C185 connector 79 pin Autosport connector
Mating connector #68086
Wire Specification
Wire
Wire to suit C185 connector: 22# Tefzel, Mil Spec : M22759/16-22
M22759/16 Wire Ratings (for various wire gauges)
Insulation Material: Tefzel
Conductor: Tin Plated Copper
Voltage Rating: 600 V
Maximum Temperature: 150
°C
Wire Gauge
[AWG] Cross
Sectional Area
[mm2] Max Current
at 100
°
C
Ambient [A]
Resistance
[ohm / m]) Resistance
[ohm / 1000 ft]
22 0.38 5 0.045 14
20 0.61 6 0.028 8.5
18 0.96 9 0.018 5.5
16 1.2 12 0.014 4.3
14 1.9 18 0.009 2.7
12 3.0 24 0.006 1.8
Crimp Tool
Crimp Tool: M22520/2-01
Positioner for Crimp Tool: M22520/2-07
Crimp Contacts are type 22D (needed to set the crimp tool correctly)
Wire Stripping Tool
Recommended: Ideal Industries 45-2133 stripping tool with LB1195 wire stop
