PARTS LIST FOR 500RGD INDEX DRIVE (STANDARD CONFIGURATION)
ITEM NO. PART NUMBER DESCRIPTION
1 ...................................................... 50D42543001002 HOUSING
2 ...................................................... 50C42559007002 INPUT SHAFT DBL EXT (W/O REDUCER)
........................................................ 50C64220007002 INPUT SHAFT DBL EXT (W/225/R260 RED)
........................................................ 50C42559007002 INPUT SHAFT DBL EXT (W/3” CONE RED)
3 ...................................................... 50D42933014006 OUTPUT SHAFT FOLL 6 HOLE 1 1/4” FOLL
........................................................ 50D42933014008 OUTPUT SHAFT FOLL 8 HOLE 1 1/4” FOLL
........................................................ 50D42933014010 OUTPUT SHAFT FOLL 10 HOLE 1” FOLL
........................................................ 50D42933014012 OUTPUT SHAFT FOLL 12 HOLE 7/8” FOLL
4 ...................................................... CAM, SPECIFY NUMBER OF STOPS AND
........................................................ INDEX TIME. (CONTACT CAMCO FOR
........................................................ ASSISTANCE IN CAM SELECTION)
5 ...................................................... 50C42554003002 CARTRIDGE, OUTPUT
6 ...................................................... 28K26335003022 CARTRIDGE, ECCENTRIC INPUT
7 ...................................................... 50B42578000000 ACCESS COVER
8* ..................................................... 50B42579000000 GASKET, ACCESS COVER
9* ..................................................... 84D07329660000 OIL SEAL C/R 42426
10* ................................................... 57B40958018800 SHIM .002 THK, UPPER OUTPUT
* ....................................................... 57B40958028800 SHIM .005 THK, UPPER OUTPUT
* ....................................................... 57B40958038800 SHIM .010 THK, UPPER OUTPUT
11* ................................................... 86D07328750022 BEARING CUP L521910
12* ................................................... 86D07328750021 BEARING CONE L521949
13 .................................................... 95A33031540000 RETAINING RING 5100-225
14 .................................................... 86D07328500021 BEARING CONE 3979
15 .................................................... 86D07328500022 BEARING CUP 3920
16 .................................................... 96A33001010000 SIGHT GLASS
17 .................................................... 95A33002010000 DRAIN PLUG
18 .................................................... 95A26010100000 LOCKWASHER W-10
19 .................................................... 95A26009100000 LOCKNUT PN-10
20* ................................................... 86D07328360021 BEARING CONE 26885
21* ................................................... 86D07328280022 BEARING CUP 26822
22* ................................................... 28A02522018800 SHIM .002 THK, INPUT
* ....................................................... 28A02522028800 SHIM .005 THK, INPUT
* ....................................................... 28A02522038800 SHIM .010 THK, INPUT
23 .................................................... 95A08089000000 SPECIAL LARGE HEAD CAPSCREW
24* ................................................... 84D07329290000 OIL SEAL C/R 16368
25* ................................................... 84D07329400000 OIL SEAL 22424
26 .................................................... 95A26003150000 BHCS 10-24 X 1/2
27 .................................................... 050K275 KEY 1/2 SQ. X 2 3/4 LARGE
28 .................................................... 95A33000010000 AIR VENT (BREATHER)
29 .................................................... 95A26012140000 SSS OVL PT 1/4-20 X 1/2
30 ................................................... 82C33150030003 FOLLOWER 7/8 DIA
........................................................ 82C33150040003 FOLLOWER 1” DIA
........................................................ 82A43724000000 FOLLOWER 1 1/4 DIA
31 .................................................... 95A26000700000 SHCS 3/8-16 X 7/8
32* ...................................................50B45872018800 SHIM .002 THK, LOWER OUTPUT
* ....................................................50B45872028800 SHIM .005 THK, LOWER OUTPUT
* .....................................................50B45872038800 SHIM .010 THK, LOWER OUTPUT
33 .....................................................50B44805003002 CARTRIDGE, LOWER OUTPUT
* Indicates parts supplied with Spare Parts Kit #500RGD SPK
