PARTS LIST FOR 1305RDM INDEX DRIVE (STANDARD CONFIGURATION)
ITEM NO. PART NUMBER DESCRIPTION
1 ...................................................... 57G41046001002 Housing
2 ...................................................... 57C42229014012 Follower Wheel 12 Hole
........................................................ 57C42229024016 Follower Wheel 16 Hole
3 ...................................................... __________ Cam, (Specify Number Of Stops And
........................................................ Index Time, Contact Camco For
........................................................ Assistance, Order In Matched Sets)
4 ...................................................... 57D40902007002 Input Shaft (W/O Reducer)
........................................................ 57D42389007002 Input Shaft (For 7350C, 30DHL)
........................................................ 57D43552007002 Input Shaft (For 7300C, 30DHL)
........................................................ 57D43807007002 Input Shaft (For 7350C)
5 ...................................................... 57C40930003002 Cartridige, Input
6 ...................................................... 57D42236000000 Retainer Bearing
7 ...................................................... 86A42226000000 Bearing
8 ...................................................... __________ Do Not Use On 1305RDM
9 ...................................................... 57B40937000000 Cover, Bottom
10* ................................................... 84A41047000000 Oil Seal C/R 1450242
11* ................................................... 84A41048000000 Oil Seal C/R 57510
12* ................................................... 57B42238018800 Shim .002
* ....................................................... 57B42238028800 Shim .005
* ....................................................... 57B42238038800 Shim .010
13 .................................................... 95A33001020000 Sight Plug 1/2-14
14* ................................................... 57B40958018800 Shim .002
* ....................................................... 57B40958028800 Shim .005
* ....................................................... 57B40958038800 Shim .010
15* ................................................... 86D07328460021 Bearing Cone 45287
16* ................................................... 86D07328460022 Bearing Cup 45220
17 .................................................... 95A26000700000 S.H.C.S. 3/8-16 X 7/8
18* ................................................... 84D07329380000 Oil Seal C/R 21336
19 .................................................... 57B40938000000 Gasket, Bottom Cover
20 .................................................... 95A26002140000 HHCS 5/16-18 X 5/8
21 .................................................... 95A33003020000 Magnetic Plug
22 .................................................... 95A33000020000 Air Vent 1/2-14
23 .................................................... 95A26009140000 Locknut
24 .................................................... 95A41521140000 Lockwasher
25 .................................................... 82C10457060003 Cam Follower
26* ................................................... 95A26005450000 S.S.S. Cup 1/4-20 X 1/2
* ....................................................... 95A26006210000 S.S.S. Cone 1/4-20 X 1/2
27 .................................................... 95A26001100000 S.H.C.S. 1/2-13 X 2 1/4
28 .................................................... 95A26001050000 S.H.C.S. 1/2-13 X 1
29 .................................................... 95A26021260000 Flat Washer 6002
30 .................................................... 062K475 Key .625 Sq. X 4.75
31 .................................................... _________ Not Used On 1305RDM
32 .................................................... 57C41192000000 Stationary Output Shaft
33 .................................................... _________ Not Used On 1305RDM
34 .................................................... 80C44620000000 Mounting Plate (For 7300C)
........................................................ 80D44630000000 Mounting Plate (For 7350C)
35 .................................................... _________ Not Used On 1305RDM
36* ................................................... 99A44547070000 Service Manual-RDM
37* ................................................... 99A44547010000 General Service Manual
* Indicates parts supplied with Spare Parts Kit #SPK1305RDM
