BatteryMINDer ® Models 12248 & 24041
Rev. C-082713 Page 13 P/N VDC12248/24041-MNL
Common Features (Both Models)
1 LED indicators ( a, b & c ) for power, connection, fault, battery, charge status
2 Battery Temperature Sensor input connector used with 10
3 Output cord with quick connect plug
4 Charge Rate selection button
5 Battery Type selection button
6 Input power cordset
7 Mounting tabs
8 Ring Terminal cordset with quick connect plug (included)
9 Battery Clip (non-insulated) cordset with quick connect plug (included)
10 ABS-248 At-the-Battery Temperature Sensor and 6’ Extension Cable (included)
8
9
10
7
3
7
a
c
b
2
5
1
6
4
