BatteryMINDer
®
Models 12248 & 24041
Rev. C-082713
Page 12
P/N VDC12248/24041-MNL
SIMPLIFIED OPERATING INSTRUCTIONS
Read and thoroughly understand ALL SAFETY Instructions, pages
3 - 10 including Preparing to Charge, DC Connection Precautions,
Unit Location and Qualifying Your Battery BEFORE proceeding
further.
1. Attach a battery connector assembly,
Ring Terminal Assembly
(
7
) or
Battery Clip Cordset (
8
), both supplied, to output cordset of
charger (
3
).
2. Attach output to battery terminals:
RED band = Positive
+
BLACK band = Negative -.
3.
Attach temperature sensor ABS-248 (
10
) to battery and then to
Temperature Sensor input connector (
2
) (if required
1
).
4. Plug
AC power cord (
5
) into a 120 Vac electrical outlet.
Observe Reversed Polarity
GREEN/RED LED indicator (
1a
):
If lit RED, reverse battery connector attachments on battery.
5. Observe
Charging/Maintaining GREEN
LED indicator (
1c
)
:
Solid = charging
Blinking = maintaining battery(s).
Charger will automatically start within 30 seconds or less.
6. Observe
Battery Connected - Error LED Indicator (
1a
):
Must be lit
GREEN
2
.
If in Doubt Regarding Any of the Above, Refer to
Detailed Operating
Instructions.
1
If battery is being charged or maintained in temperatures as low as 32°F to a
high of 125°F this sensor must be used.
2
See full instructions if not lit
GREEN.
