DETAILED SPECIFICATIONS -
VDC Model No. 12248-A-ODY (con’t.)
Battery sulphation check period (After absorption charge is
finished): 10 minutes
Unloaded output voltage when battery is disconnected: 0.5
Vdc (max.)
Output short-circuit current when battery disconnected:
5mA dc (max.)
Battery flow back current (to the charger) when connected to
12V battery, AC Power disconnected:
30 (max.) mA dc
All LED indicators will shut off if AC power is disconnected for
10 Minutes
Full time Desulphation output pulse current control Ip-p ±3
Adc
Full time Desulphation output PWM* frequency 100 ±10Hz
Full time Desulphtation duty 0.3%
*Pulse Width Modulated
Temperature Compensation (with ABS-248 Battery Tempera-
ture Sensor)
Temperature at the Posi-
tive Terminal of Battery
Temperature Ranges
Odyssey Float
>120°F/>49°C 14.1 12.9 ±0.25 Vdc
110-120°F/43-49°C 14.2 13.0 ±0.25 Vdc
100-110°F/38-43°C 14.3 13.1 ±0.25 Vdc
90-100°F/32-38°C 14.4 13.2 ±0.25 Vdc
80-90°F/27-32°C 14.5 13.4 ±0.25 Vdc
70-80°F/21-27°C 14.6 13.5 ±0.25 Vdc
60-70°F/16-21°C 14.8 13.7 ±0.25 Vdc
40-50°F/4-10°C 15.2 14.0 ±0.25 Vdc
>40°F/>4°C 15.4 14.2 ±0.25 Vdc
