Page 9
9
Note: Not all components of the pump are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
MODEL:
HU3002T
Single Acting Aluminum
Cylinders Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or
damaged parts with BVA Hydraulics Authorized Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item
Part Number
Description
Qty
1
649-1-0060-040
Bolt
2
2
M12-6-1101-108
Saddle
1
3
N/A
Upper Bearing Assy
1
3-1
M13-6-1701-109 Upper Bearing
1
3-2
599-7-0600-107
Wear Ring
1
3-3
542-7-0600-007
Wiper Seal
1
4
644-1-0060-200
Bolt
1
5
H25-4-0202-101
Return Spring Assy
1
6
N/A
Cylinder
1
7
N/A
Ram Assy
1
7-1
N/A
Ram
1
7-2
M13-6-1501-101 Bearing
1
7-3
579-7-0750-009
Back-up Ring
1
7-4
522-7-0750-000
U-cup
1
8
532-3-0060-100
Special Washer
1
9
649-1-0060-104
Bolt
2
10
M13-6-1601-105 Base Plate
1
11
642-1-0060-05911 Screw
4
12
CH38F
Coupler
1
13
H02-6-1008-105
Rubber Cap
1
14
H02-4-6003-108
Dust Cap Assy
1
(*)
M13-3-9902-101 Seal Kit
-
Parts List
