Page 15
15
Note: Not all components of the pump are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
MODELS: HU5004T, HU5006T & HU5010T
Single Acting Aluminum
Cylinders Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or damaged
parts with BVA Hydraulics Authorized Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item
Part Number
Description
Qty
HU5004T
HU5006T
HU5010T
1
649-1-0010-109
Bolt
2
2
H55-6-1103-100
Saddle
1
3
649-1-0100-302
Bolt
2
4
515-3-0115-104
Washer
2
5
M15-4-1701-101
Upper Bearing Assy
1
5-1
M15-6-1701-103
Upper bearing
1
5-2
*599-7-0800-206
Wear Ring
1
5-3
*541-7-0800-109
Wiper Seal
1
6
H15-4-0204-109
M15-4-0506-108
M15-4-0510-109
Return Spring Assy
1
7
M15-6-1804-103
M15-6-1806-107
M15-6-1810-108
Cylinder
1
8
M15-4-1204-107
M15-4-1206-101
M15-4-1210-102
Ram Assy
1
8-1
M15-6-1204-109
M15-6-1206-103
M15-6-1210-104
Ram
1
8-2
H55-5-1204-100
Bearing
1
8-3
*579-7-0950-108
Back-up Ring
1
8-4
*522-7-0950-301
U-cup
1
9
M15-6-1601-109
Base Plate
1
10
642-1-0060-05911
Screw
4
12
CH38F
Coupler
1
13
H02-6-1008-105
Rubber Cap
1
14
H02-4-6003-108
Dust Cap Assy
1
15
M15-6-1401-101
Handle
1
16
649-1-0060-040
Bolt
2
(*)
M15-3-9901-103
Seal Kit
-
Parts List
