Note: Not all components of the pump are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
MODELS: HU2002T, HU2004T & HU2006T
Single Acting Aluminum
Cylinders Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or
damaged parts with BVA Hydraulics Authorized Replacement Parts
only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item
Part Number
Description
Qty
HU2002T
HU2004T
HU2006T
1
649-1-0060-040
Bolt
2
2
M12-6-1101-108
Saddle
1
3
M12-4-1701-100
Upper Bearing Assy
1
3-1
M12-6-1701-102
Upper Bearing
1
3-2
599-7-0500-103
Wear Ring
1
3-3
542-7-0508-100
Wiper Seal
1
4
644-1-0060-200
649-1-0060-104
Bolt
1
5
H10-4-0202-209
H10-4-0204-102
H10-4-0206-106 Return Spring Assy
1
6
M12-6-1802-108
M12-6-1804-102
M12-6-1806-106 Cylinder
1
7
M12-4-1202-102
M12-4-1202-106
M12-4-1206-100 Ram Assy
1
7-1
M12-6-1202-104
M12-6-1202-106
M12-6-1206-102 Ram
1
7-2
M12-6-1501-104
Bearing
1
7-3
579-7-0630-201
Back-up Ring
1
7-4
522-7-0630-202
U-cup
1
8
532-3-0060-100
Special Washer
2
9
649-1-0060-205
649-1-0060-104
Bolt
2
10
M12-6-1601-108
Base Plate
1
11
642-1-0060-05911
Screw
4
12
CH38F
Coupler
1
13
H02-6-1008-105
Rubber Cap
1
14
H02-4-6003-108
Dust Cap Assy
1
(*)
M12-3-9902-104
Seal Kit
-
Parts List
