Page 13
13
Note: Not all components of the pump are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
MODEL: HU5002T
Single Acting Aluminum
Cylinders Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or
damaged parts with BVA Hydraulics Authorized Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item
Part Number
Description
Qty
1
649-1-0010-109
Bolt
2
2
M55-6-1103-100
Saddle
1
3
N/A
Upper Bearing Assy
1
3-1
M15-6-1701-103
Upper bearing
1
3-2
*599-7-0800-206
Wear Ring
1
3-3
*541-7-0800-109
Wiper Seal
1
4
644-1-0100-105
Bolt
5
H55-4-0202-105
Return Spring Assy
1
6
N/A
Cylinder
1
7
N/A
Ram Assy
1
7-1
M15-6-1202-105
Ram
1
7-2
M55-5-1204-100
Bearing
1
7-3
*579-7-0950-108
Back-up Ring
1
7-4
*522-7-0950-301
U-cup
1
8
515-3-0115-104
Washer
1
9
649-1-0100-302
Bolt
1
10
M15-6-1601-109
Base Plate
1
11
642-1-0060-05911
Screw
4
12
CH38F
Coupler
1
13
H02-6-1008-105
Rubber Cap
1
14
H02-4-6003-108
Dust Cap Assy
1
15
M15-6-1401-101
Handle
1
16
649-1-0060-040
Bolt
2
(*)
M13-3-9901-109
Seal Kit
-
Parts List
