11
Note: Not all components of the pump are replacement items, but are illustrated as a convenient
reference of location and position in the assembly sequence.
MODEL: HU3004T & HU3006T
Single Acting Aluminum
Cylinders Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA
Hydraulics Authorized Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item
Part Number
Description
Qty
HU3004T
HU3006T
1
649-1-0060-040
Bolt
2
2
M12-6-1101-108
Saddle
1
3
*649-1-0060-104
Bolt
2
4
*532-3-0060-100
Special Washer
2
5
N/A
Upper Bearing Assy
1
5-1
M13-6-1701-109
Upper bearing
1
5-2
*599-7-0600-107
Wear Ring
1
5-3
*542-7-0600-007
Wiper Seal
1
6
H25-4-0204-105
H25-4-0206-109
Return Spring Assy
1
7
N/A
Cylinder
1
8
N/A
Ram Assy
1
8-1
N/A
Ram
1
8-2
M13-6-1501-101
Bearing
1
8-3
*579-7-0750-009
Back-up Ring
1
8-4
*522-7-0750-000
U-cup
1
9
M13-6-1601-105
Base Plate
1
10
642-1-0060-05911
Screw
4
11
CH38F
Coupler
1
12
H02-6-1008-105
Rubber Cap
1
13
H02-4-6003-108
Dust Cap Assy
1
(*)
M13-3-9901-109
Seal Kit
-
Parts List
