SPECIFICATIONS
test leads.
— Test Lead Continuity:
S
— Insulation resistance
Measuring range :
0-200M (250V,500V DC ±10%)
Resolution : 1 count / 100K
0-2000M
(1000V DC ±10%)
Resolution : 1 count / 1M
Accuracy : ±1.5% rdg. ±5dgt. (200M range
±3%rdg. ±3dgt. (under 1G / 2000M
±5%rdg. ±5dgt. (under 2G 2000M
Output current :
1 mA DC min. at 0.25 M (250V range)
1 mA DC min. at 0.5 M (500V range)
1 mA DC min. at 1 M (1000V range)
Power consumption : Max. consumption current
approx. 250mA .
— AC voltage
Range : 0-600V.
Resolution : 1V.
Accuracy : ±1.5%rdg. ±3dgt.
Line frequency range : 40 -120 Hz .
— Continuity
Ohm range : 0-20
Resolution : 0.01
Accuracy : ±1.5%rdg. ±5dgt.
Ohm range : 0-2000
Resolution : 1
Accuracy : ±1.5%rdg. ±3dgt.
Open circuit terminal voltage : 4 V DC min.
Short circuit terminal current : 210 mA DC min.
Power consumption: Max. consumption current
approximately 160mA
Buzzer sound below : under 10 (on 20 range)
— Withstand :Meet IEC-1010 safety requirements
Category .
— Dimension :170 165 92 mm 6.7 6.5 3.6 inch
with housing front cover
— Weight : 1.04 kg ( battery included )
— Standard Accessories :
Batteries 1.5V , size AA (R6) 8 pieces
Test Leads 1 pair
Fuse 0.5A , 250V 1 piece
Instruction Manual 1 vol.
-8- -9-
