-9- -8-
PREPARATION FOR USE
Fuses:
In doubt, check the fuses using a ohm meter.
Please note that this instrument will not indicate anything, should the
fuses be blown.
Test Leads:
Check the test leads for defects or cracks. Replace if cracked or
damaged. Only replace with the same type
Cleaning:
REPLACING THE BATTERIES
Prior to battery replacement always disconnect the instrument from
the circuit to which it's connected.
Remove the test leads from the instrument.
Remove the back cover to access the battery compartment.
Remove the bad battery from the battery compartment and dispose
properly of that battery (see your local disposal facilities related to
disposal of batteries).
Only replace with a new battery of the following type:
9 V, IEC 6 LR61.
Re-insert the (battery) back cover onto the instrument and tighten
the screws.
Clean the instrument case with an anti-static cleaner and wipe with
dry cloth.
FUSES REPLACEMENT
Unscrew the back cover and replace the faulty fuse(s) with the same
type, then screw the cover back into place correctly
SPECIFICATIONS
ELECTRICAL
Determination of the Phase Presence
Nominal Voltage for Phase Presence Indication (the voltage required
for the neon lamps L1, L2, L3 to lit up) ... From 100Vac to 600Vac.
Frequency Range ................................... From 10Hz to 400Hz.
Determination of the Phases Rotary Field Direction:
Direction (the voltage required to have the direction LEDs L1-L2-L3
or L2-L1-L3 to indicates) ......................... From 1 to 600Vac.
Frequency Range ................................... From 2Hz to 400Hz.
Determination of Motor Connections (requires > turn)
Direction (the voltage required to have the direction LEDs L1-L2-L3
or L2-L1-L3 to indicates) ........................ From 1 to 600Vac.
Frequency Range .................................. From 2Hz to 400Hz.
Protection
Over Load .............................................. 550V
(between all terminals)
Over Voltage .......................................... Class III - 600V towards
Ground.
Fuses...................................................... 5 x 20mm, 200mA,
250V fuse
General
Battery .................................................... 9V, IEC 6LR61
Current Consumption ............................. Max 18 mA.
MECHANICAL
Size ......................................................... 151 x 72 x 35 mm
Material ................................................... Poly carbonate/ABS
Weight (less carrying case) .................... 180g (with batteries)
Display .................................................... Neon Lamps and LEDs
ENVIRONMENTAL
Operating temperature Range:
-15 °C to + 55 °C
Storage Temperature: -20 °C to + 70 °C
1 2
