Data Sheet
Model 301
AC Line Separator
AC Line Separator
Model 301
The 301 is intended to be used with an AC Current Clamp Meter.
It provides temporary separation of conductors to facilitate meas-
urement of current. Most 120Vac devices use a two conductor
power cord which makes it difficult to isolate a single conductor to
make a current measurement. A single conductor is required to
make a measurement because a two conductor measurement will
cancel each other out.
Features
■ X10 Mode allows for more accurate measurements
of low amperage devices
■ Direct reading in X1 mode
■ 2mm Voltmeter measurement points
■ Integrated ground conductor (three pronged US
standard plug)
■ 15 amp capacity
Applications
■ Monitor a devices power consumption
■ Measure surge current
