4 w w w.bk prec ision.c om
Dual-Display Handheld LCR Meters
Models 878B and 879B
Specifications (cont.)
Range Max D isplay Cx Accuracy DF (Dx <0.5) Me as urement Mode
20 mF 20.000 mF 8% + 3 digits 8% + 50 digits Series
4000 μF 3999.9 μF 2% + 2 digits 2% + 50 digits Series
400 μF 399.99 μF 0.7% + 2 digits 0.7% + 50 digits Series
40 μF 39.999 nF 0.5% + 1 digits 0.5% + 50 digits Series
4000 nF 3999.9 nF 0.5% + 1 digits 0.5% + 50 digits Series/ Parallel
400 nF 399.99 nF 0.5% + 2 digits 0.5% + 50 digits Series/ Parallel
40 nF 39.999 nF 0.7% + 1 digits 0.7% + 50 digits Parallel
4 nF 3.9999 nF 2.5% + 2 digits 2.5% + 50 digits Parallel
1000 μF 1000.0 μF 3.7% + 3 digits 3.7% + 50 digits Series
400 μF 399.99 μF 2% + 2 digits 2% + 50 digits Series
40 μF 39.999 μF 0.7% + 2 digits 0.7% + 50 digits Series
4000 nF 3999.9 nF 0.5% + 1 digit 0.5% + 50 digit Series
400 nF 399.99 nF 0.5% + 2 digits 0.5% + 50 digits Series/ Parallel
40 nF 39.999 nF 0.5% + 2 digits 0.5% + 50 digits Series/ Parallel
4000 pF 3999.9 pF 0.7% + 2 digits 0.7% + 50 digits Parallel
400 pF 399.9 pF 2.5% + 2 digits 2.5% + 50 digits Parallel
100 μF 100.00 μF 3.9% + 5 digits 3.9% + 50 digits Series
40 μF 39.999 μF 3.7% + 3 digits 3.7% + 50 digits Series
4000 nF 3999.9 nF 0.7% + 2 digits 0.7% + 50 digits Series
400 nF 399.99 nF 0.5% + 2 digits 0.5% + 50 digits Series
40 nF 39.999 nF 0.5% + 1 digit 0.5% + 50 digit Series/ Parallel
4000 pF 3999.9 nF 0.5% + 2 digits 0.5% + 50 digits Series/ Parallel
400 pF 399.99 pF 0.7% + 2 digits 0.7% + 50 digits Parallel
40 pF 39.99 pF 2.5% + 2 digits 2.5% + 50 digits Parallel
E
S
R
*
Range M ax Display R/Zx Accuracy θ Accuracy* Measu rement Mode
10 MΩ 10.000 MΩ 5.5% + 3 digits ±3.2° Parallel
4000 kΩ 3999.9 kΩ 2.5% + 2 digits ±1.5° Parallel
400 kΩ 399.99 kΩ 0.7% + 2 digits ±0.4° Parallel
40 kΩ 39.999 kΩ 0.5% + 2 digits ±0.3° Series/ Parallel
4000 Ω 3999.9 Ω 0.5% + 2 digits ±0.3° Series/ Parallel
400 Ω 399.99 Ω 0.5% + 2 digits ±0.3° Series
40 Ω 39.999 Ω 0.7% + 2 digits ±0.4° Series
4 Ω 3.9999 Ω 2.0% + 2 digits ±1.2° Series
Range Max Display ESR Accuracy Measu rement Mode
1000 Ω 999.9 Ω 0.5% + 2 digits Series
100 Ω 99.99 Ω 0.5% + 2 digits Series
10 Ω 9.999 Ω 0.7% + 2 digits Series
1 Ω .9999 Ω 2.0% + 2 digits Series
1
0
0
H
z
/1
2
0
H
z
/
1
k
H
z
/
1
0
k
H
z
v091713
C
a
p
a
c
it
a
n
c
e
1
0
0
H
z
*
/1
2
0
H
z
1
k
H
z
1
0
k
H
z
*
R
e
s
is
ta
n
c
e
/I
m
p
e
d
a
n
c
e
*
1
0
0
H
z
/1
2
0
H
z
/
1
k
H
z
/1
0
k
H
z
* = Model 879B only
*
*
