Multiformat Video Generator — TG700
Characteristic Description
100%/75% Color Bars
100%/75% Color Bars over Red
40%/50%/100% Flat Field
Black Burst
Black Burst with No Field Reference
Field Square Wave
5/10 Step
Ramp
Modulated 5/10 Step
Modulated Ramp
Modulated Pedestal
Shallow Ramp
Convergence
2/4 Level Pedestal and Pluge
100%/75% Red Field
Gray/White Window
Safe Area
Monitor Setup Matrix
100% Multiburst
Multipulse
100%/75% Sweep
Window 2T Pulse and Bar
Sin (x)/x
CCIR 17/18/330/331
UK ITS 1/2
UK 1 Line ITS
ITS Matrix and 0-100% Bounce PAL Test Signals
APL High/Low, APL Bounce
Max 18 characters. One row (character 14×11 pixels)
ID Text
Text and Position is embedded to each signal
Luminance Amplitude ±1% (measured at 700 mV)
Chrominance-to-
Luminance Gain
±1%
Frequency Response ±1% to 5.5 MHz
Chrominance-to-
Luminance Delay
≤10 ns
Linearity ≤1% (measured at 5 step signal)
Differential Gain Error ≤0.5%
Differential Phase Error ≤0.5°
BARS Output
Characteristic Description
100%/75% Color Bars
SMPTE Color Bars
40% Flat Field
Black Burst
Black Burst with Field REF NTSC/NTSC No Setup
Signals
Monitor Setup, SNG Color Bars
100%/75% Color Bars
100%/75% Color Bars over RED
40% Flat Field
Black Burst
Black Burst with No Field REF
PAL Signals
Monitor Setup, SNG Color Bars
Max 18 characters. One row (character 14×11 pixels)
ID Text
Text and Position is embedded to each signal
Luminance Amplitude ±1% (measured at 700 mV)
Chrominance-to-
Luminance Gain
±2%
BLACK 1/2 Outputs
Characteristic Description
NTSC/NTSC No Setup
Signals
Black Burst, Black Burst with Field Reference,
Subcarrier, Composite Sync, H Drive, V Drive,
Composite Blanking, and Color Frame ID
PAL Signals Black Burst, Black Burst with Field Reference,
Subcarrier, Composite Sync, H Drive, V Drive,
Composite Blanking, Color Frame ID, and PAL Pulse
Timing Pulse Amplitude –0.5 to 0.5 V (1 V
p-p
)
SIGNAL, BARS, and BLACK 1/2 (Common)
Characteristic Description
ITU-R BT.470-6
PAL-M and PAL-N are not supported
Standards
SMPTE 170M
Output Impedance 75 Ω
Return Loss ≥36 dB to 6 MHz
Burst Amplitude ±2%
Sync Amplitude ±2%
Blanking Level 0 mV ±50 mV
SCH Phase Accuracy 0° ±5°
Timing Offset Range Full color frame
Timing Offset Resolution 54 MHz clock resolution
