Real-time Spectrum Analyzers
RSA2200A Series • RSA3300A Series
Marker Frequency Readout Accuracy –
± (RE x MF + 0.001 x Span + RFM ) Hz.
RE = Reference Frequency Error.
MF = Marker Frequency [Hz].
RFM = Residual FM [Hz].
Carrier Frequency Measurement Accuracy –
RSA2203A and RSA2208A
At spans
≤ 10 MHz, all frequency components of
the signal must be contained in the analysis period
and span.
Accuracy: RE x CF + RFM. Resolution Setting =
1 mHz to 1 MHz.
At 2 GHz ±4.01 kHz.
At 5 GHz ±10.01 kHz.
At 7 GHz ±14..01 kHz.
RSA2203A Opt. 10, RSA2208A Opt. 10,
RSA3303A and RSA3308A –
At spans
≤ 10 MHz for RSA2200A Opt. 10, and
spans ≤15 MHz for RSA3300A, all frequency
components of the signal must be contained in
the analysis period and span.
Accuracy: RE x CF + RFM. Resolution Setting =
1 mHz to 1 MHz.
At 2 GHz ±202 Hz.
At 5 GHz ±502 Hz.
At 7 GHz ±702 Hz.
Carrier Frequency Measurement Sensitivity –
Carrier Power, >–40 dbfs (typical) (dBfs = dB below
full screen reference).
Frequency Span
Range –
RSA2203A and RSA2208A
Spectrum Analyzer Mode:
50 Hz to 3 GHz, (Start Frequency ≥20 MHz).
50 Hz to 20 MHz, (Stop Frequency
< 20 MHz, Opt.05).
Real-Time Spectrum Analyzer Mode:
100 Hz – 10 MHz, 1-2-5 sequence (RF);
20 MHz (Baseband).
Time Domain and Demodulation Modes:
Span = 0 Hz (Simultaneous with 50 Hz to
10 MHz Span in second analysis window).
RSA3303A and RSA3308A
Spectrum Analyzer Mode:
50 Hz to 3 GHz, (Start Frequency ≥20 MHz).
50 Hz to 20 MHz, (Stop Frequency < 20 MHz).
Real-Time Spectrum Analyzer Mode:
100 Hz – 10 MHz, 15 MHz (RF);
20 MHz (Baseband).
Time Domain and Demodulation Modes:
Span = 0 Hz (Simultaneous with 50 Hz to
15 MHz Span in second analysis window).
Resolution – < 0.2% of Span (Span = 100 Hz to
10 MHz RSA2203A and RSA2208A; 100 Hz to
10 MHz, 15 MHz, RSA3303A and RSA3308A).
Accuracy – ±0.1% of Span.
Resolution Bandwidth
Range – 1 Hz to 10 MHz, automatically selected or
user defined.
Accuracy – Within 6.0% ±0.1%.
Shape Characteristic – Gaussian, <5:1 Shape
Factor (3:60 dB); Rectangular, Nyquist, Root
Nyquist shapes may also be selected.
Noise Bandwidth –
Range: 313.18 mHz to 400.87 kHz
Accuracy: ±0.1%
FFT Performance
Number of Samples Per Frame – 64 to 8192
(65536 samples / frame, extended resolution).
Window types –
Rectangular, Parzen, Welch, Sine-Lobe, Hanning,
Sine-Cubed, Sine-To-The-4th, Hamming, Blackman,
Rosenfield, Blackman-Harris 3A, Blackman-Harris 3B,
Blackman-Harris 4A, Blackman-Harris 4B, FlatTopn.
N o i s e S i d e b a n d s , d B c / H z
At 1 GHz CF RSA2203A, RSA3303A,
RSA2208A RSA3308A
Offset Spec Typical Spec Typical
1 kHz ≤–99 ≤–102 ≤–100 ≤–103
10 kHz ≤–105 ≤–108 ≤–105 ≤–108
20 kHz ≤–105 ≤–108 ≤–105 ≤–108
30 kHz ≤–105 ≤–108 ≤–105 ≤–108
100 kHz ≤–112 ≤–115 ≤–112 ≤–115
1 MHz ≤–130 ≤–133 ≤–132 ≤–135
5 MHz ≤–132 ≤–135 ≤–135 ≤–138
7 MHz ≤–133 ≤–136 ≤–135 ≤–138
At 2 GHz CF RSA2203A, RSA3303A,
RSA2208A RSA3308A
Offset Spec Typical Spec Typical
1 kHz ≤–95 ≤–98 ≤–96 ≤–99
10 kHz ≤–104 ≤–107 ≤–104 ≤–107
20 kHz ≤–105 ≤–108 ≤–105 ≤–108
30 kHz ≤–105 ≤–108 ≤–105 ≤–108
100 kHz ≤–112 ≤–115 ≤–112 ≤–115
1 MHz ≤–130 ≤–133 ≤–132 ≤–135
5 MHz ≤–132 ≤–135 ≤–135 ≤–138
7 MHz ≤–132 ≤–135 ≤–135 ≤–138
At 6 GHz CF RSA2208A RSA3308A
Offset Spec Typical Spec Typical
1 kHz ≤–87 ≤–90 ≤–87 ≤–90
10 kHz ≤–103 ≤–106 ≤–104 ≤–107
20 kHz ≤–105 ≤–108 ≤–105 ≤–108
30 kHz ≤–105 ≤–108 ≤–105 ≤–108
100 kHz ≤–111 ≤–114 ≤–112 ≤–115
1 MHz ≤–128 ≤–131 ≤–128 ≤–131
5 MHz ≤–129 ≤–132 ≤–130 ≤–133
7 MHz ≤–130 ≤–133 ≤–130 ≤–133
Residual FM at 1 kHz RBW –
RSA2203A and RSA2208A: 10 Hz
p-p
; 2 Hz
p-p
(Opt. 10).
RSA3303A and RSA3308A: 2 Hz
p-p
.
Stability
