Data Sheet
Acquisition Modes
Peak Detect – High-frequency and random-glitch capture. Captures glitches as
narrow as 12 ns (typical) using acquisition hardware at all time base settings from
5 μs/div to 50 s/div.
Sample – Sample data only.
Average – Waveform averaged, selectable: 4, 16, 64, 128.
Single Sequence – Use the Single Sequence button to capture a single triggered
acquisition sequence at a time.
Roll Mode – At acquisition time base settings of >100 ms/div.
Trigger System
Trigger Modes – Auto, Normal, Single Sequence.
Trigger Types
Edge (rising/falling) – Conventional level-driven trigger. Positive or negative slope on
any channel. Coupling selections: AC, DC, Noise Reject, HF Reject, LF Reject.
Video – Trigger on all lines or individual lines, odd/even or all fields from composite
video, or broadcast standards (NTSC, PAL, SECAM).
Pulse Width (or Glitch) – Trigger on a pulse width less than, greater than, equal to, or
not equal to, a selectable time limit ranging from 33 ns to 10 s.
Trigger Source
2-channel Models – CH1, CH2, Ext, Ext/5, AC Line.
4-channel Models – CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line.
Trigger View
Displays trigger signal while trigger view button is depressed.
Trigger Signal Frequency Readout
Provides a frequency readout of the trigger source.
Cursors
Types – Amplitude, Time.
Measurements – [Δ]T, 1[Δ]T (frequency), [Δ]V.
Automatic Waveform Measurements
Period, Frequency, +Width, -Width, Rise Time, Fall Time, Max, Min, Peak-to-Peak,
Mean, Cycle RMS.
Waveform Math
Operators – Add, Subtract, Multiply, FFT.
FFT – Windows, Hanning, Flat Top, Rectangular, 2048 sample points.
Sources –
2-channel models: CH1 - CH2, CH2 - CH1, CH1 + CH2, CH1 × CH2
4-channel models: CH1 - CH2, CH2 - CH1, CH3 - CH4, CH4 - CH3, CH1 + CH2,
CH3 + CH4, CH1 × CH2, CH3 × CH4
Autoset Menu
Single-button, automatic setup of all channels for vertical, horizontal, and trigger
systems, with undo Autoset.
Signal Type Autoset Menu Choices
Square Wave Single-cycle, Multicycle, Rising or Falling
Edge
Sine Wave Single-cycle, Multicycle, FFT Spectrum
Video (NTSC, PAL, SECAM) Field: All, Odd, or Even
Line: All or Selectable Line Number
Autorange
Automatically adjust vertical and/or horizontal oscilloscope settings when probe is
moved from point to point, or when the signal exhibits large changes.
Display Characteristics
Display –
Color models: ¼ VGA passive color LCD with color on black background with
adjustable multilevel contrast.
Monochrome models: ¼ VGA backlit passive LDC with adjustable multilevel contrast
and inverse video selectable from front panel.
Interpolation – Sin(x)/x.
Display Types – Dots, vectors.
Persistence – Off, 1 s, 2 s, 5 s, infinite.
Format – YT and XY.
Environmental and Safety
Temperature –
Operating: 0 to +50 ºC.
Nonoperating: -40 to +71 ºC.
Humidity –
Operating and Nonoperating: Up to 80% RH at or below +40 ºC.
Operating and Nonoperating: Up to 45% RH up to +50 ºC.
Altitude –
Operating and Nonoperating: Up to 3,000 m.
Electromagnetic Compatibility – Meets Directive 89/336/EEC, amended by
93/68/EEC, meets or exceed EN55011 Class A Radiated and Conducted
Emissions; FCC 47 CFR, Part 15, Subpart B, Class A; Australian EMC Framework,
demonstrated per Emission Standard AS/NZS 2064; Russian GOST EMC
regulations.
Safety – UL610100-1:2003, CSA22.2 No. 61010-1:2003, EN61010-1:2001,
IEC61010-1:2001.
Physical Characteristics
Instrument
Dimensions
mm in.
Width 326.3 12.85
Height 158.0 6.22
Depth 124.2 4.89
Weight kg lb.
Instrument Only 2.0 4.4
with accessories 2.2 4.9
Instrument Shipping
Package Dimensions
mm in.
Width 476.2 18.75
Height 266.7 10.5
Depth 228.6 9.0
RM2000B Rackmount mm in.
Width 482.6 19.0
Height 177.8 7.0
Depth 108.0 4.25
