High-performance Differential Probes — P7350 • P7330 • P6330
Ordering Information
P7350
5.0 GHz Differential Probe for TekConnect Interface.
Supports CSA/TDS8200, CSA/TDS8000, TDS/CSA7000/B, and TDS6000/B/C
Series.* 1
P7330
3.5 GHz Differential Probe for TekConnect Interface.
Supports CSA/TDS8200, CSA/TDS8000, TDS/CSA7000/B, and TDS6000/B/C
Series.* 1
P6330
3.5 GHz Differential Probe for TEKPROBE ® BNC Interface.
Supports TDS/CSA7000/B, TDS6000/B/C, TDS700, TDS600 Series.* 2
All Include: One-year warranty, plus see Accessories table below.
* 1 CSA/TDS8200, CSA/TDS8000 Series requires the use of the 80A03 TekConnect Interface Adapter.
* 2 TDS6000/B/C or TekConnect TDS7000/B Series oscilloscopes require a TCA-BNC adapter.
Accessories
P7350 P7330 P6330 Accessory
Part No. Quantity Part No. Quantity Part No. Quantity
Y Lead Adapter 196-3434-xx 2 each 196-3434-xx 2 each 196-3434-xx 2 each
3 in. Ground Lead 196-3469-xx 2 each 196-3469-xx 2 each 196-3469-xx 2 each
SMT KlipChip™
Adapter
206-0364-xx 2 each 206-0364-xx 2 each 206-0364-xx 2 each
TwinFoot™ Adapter
(Pkg of 2)
016-1785-xx 1 pkg 016-1785-xx 1 pkg 016-1785-xx 1 pkg
Square Pin Adapter
(Pkg of 4)
016-1884-xx 1 pkg 016-1884-xx 1 pkg 016-1884-xx 1 pkg
Plastic Accessory Box 006-7164-xx 1 006-7164-xx 1 006-7164-xx 1
Coding Color Marker
Kit
016-1886-xx 1 – – – –
Color-coding Clips
– –
016-1315-xx 1 set 016-1315-xx 1 set
Variable Spacing
Adapter
(pkg of 4)
016-1885-xx 1 pkg 016-1885-xx 1 pkg 016-1885-xx 1 pkg
Probe Carrying Case 016-1879-xx 1 016-1879-xx 1 016-1879-xx 1
Instruction Manual 071-1238-xx 1 071-0758-xx 1 071-0757-xx 1
Certificate of Traceable
Calibration
–
1
–
1
–
1
Antistatic Wrist Strap 006-3415-04 1 006-3415-04 1 006-3415-04 1
Pin Jumper Lead 196-3473-xx 2 196-3473-xx 2 196-3473-xx 2
Solder In Kit 020-2505-xx 1
– – – –
Service
Opt. C3 – Calibration Service 3 Years.
Opt. C5 – Calibration Service 5 Years.
Opt. D1 – Calibration Data Report.
Opt. D3 – Calibration Data Report 3 Years (with Opt. C3).
Opt. D5 – Calibration Data Report 5 Years (with Opt. C5).
Opt. G3 – Complete Care 3 Years (includes loaner, scheduled calibration and more).
P7330, P7350 only
Opt. G5 – Complete Care 5 Years (includes loaner, scheduled calibration and more).
P7330, P7350 only
Opt. R3 – Repair Service 3 Years.
Opt. R5 – Repair Service 5 Years.
Opt. SILV900 – Standard Warranty Extended to 5 Years. P6330 only
Recommended Accessories
IEEE 1394 Breakout Connector – Order 679-5027-xx.
IC Grabber – Order 013-0309-xx (Pkg of 2).
Related Products
1103 – TEKPROBE ® II power supply for interfacing with other BNC instruments
80A03 – TekConnect probe interface module for TDS/CSA8000 Series oscilloscopes.
Power Plug Options for 1103
A0 – North America power.
A1 – Universal EURO power.
A2 – United Kingdom power.
A3 – Australia power.
A4 – 240 V, North America power.
A5 – Switzerland power.
CE Marking Not Applicable.
Tektronix is registered to ISO 9001 and ISO 14001 by SRI Quality System Registrar.
www.tektronix.com 3
