SPECIFICATIONS
9306
Size Range 0.3 to 25 µm
Particle Channel
Sizes
9306-03: 0.3, 0.5, 0.7, 1.0, 2.0, 5.0 µm
9306-04: 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 µm
9306-V2: 0.3 to 10 µm, user-selectable; factory-
calibrated at 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 µm
Size Resolution <15% @ 0.5 µm (per ISO 21501-4 requirements)
Counting Efficiency
50% at 0.3 µm; 100% for particles >0.45 µm (per ISO
21501-4 and JIS)
Concentration Limit
5,950,00 particles/ft 3 (210,000,000/m 3 )
@ 10% coincidence loss
Light Source Long life laser diode
Zero Count <1 count per 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate
0.1 CFM (2.83 L/min) with ±5% accuracy (meets ISO
21501-4 and JIS requirements)
Flow Rate Control
Electronic, automatic closed loop (patented* flow
control technology)
Calibration NIST Traceable with TSI calibration system
Calibration
Frequency
Recommended minimum once per year
Sampling Modes
Manual, automatic, beep; cumulative/differential;
count or concentration
Sampling Time 1 second to 99 hours
Sampling Frequency 1 to 9999 cycles or continuous
Exhaust
Internally HEPA filtered
Communication Mode Modbus® TCP over Ethernet or USB
Alarm Status Audible alarm on counts
Status Indicators Low battery, flow, laser
Environmental
Sensors
Optional Temp/RH probe
Display QVGA 3.5-inch (8.9-cm) touch screen
Reports
Provides Pass/Fail on ISO 14644-1, EU GMP, and
FS209E reports
Unit ID Configurable IP address
Security
2-level password protection to lock out usage and
configuration
Data Storage
250 Zones
999 Locations
10,000 sample records including: date, time, six total
particle size channels, flow status, and instrument status
Data Transfer
Via USB storage device, connection to TrakPro™ Lite
Secure software through Ethernet or USB cable, or
optional TSI FMS software
Languages
English, Japanese, German, French, Spanish, and
Chinese (simplified), Italian
Software
Compatible with TrakPro™ Lite, TrakPro™ Lite Secure
and FMS 5 Software
External Surface High Impact injection molded plastic
Dimension
(H x W x D)
9.4 in. x 4.6 in. x 4.9 in. (23.9 cm x 11.7 cm x 12.4 cm)
(without isokinetic inlet, includes handle)
Weight 2.2 lb (1.0 kg) with battery
Power
110 to 240 VAC, 50 to 60 Hz universal in-line power
supply
Battery Removeable/rechargeable Li-Ion
Battery Life >6 hours of continuous use
Recharge Time <2 hours
Standards ISO 21501-4, CE, JIS B9921
Warranty Two years, extended warranties available
Operating Range 41˚to 95˚F (5˚ to 35˚C), 20% to 95% noncondensing
Storage Range 32˚ to 122˚F (0˚ to 50˚C), up to 98% RH noncondensing
Included Accessories
Operating manual on CD, power supply, battery,
isokinetic inlet, purge filter, stylus, USB cable and
TrakPro™ Lite Secure
Optional Accessories
Spare Battery, external battery charger, isokinetic
probe, sample tubing, Temp/RH probe, printer, printer
paper and carrying case
AEROTRAK HANDHELD PARTICLE COUNTER
MODEL 9306
*Patent Number 6,167,107
Specifications are subject to change without notice.
