A d v a n c e d Te s t S o l u t i o n s f o r E M C

Technical specifications

Teseq AG
Nordstrasse 11F 4542 Luterbach Switzerland
T + 41 32 681 40 40 F + 41 32 681 40 48
[email protected]

www.teseq.com

data line coupling/decoupling network

cdn 117

691-257A September 2009

Signal line:
Max operatng voltage:

AC

250 V

DC

250 V

Max operating current:

1.5 A

Ohmic resistance per path:

<2.5 Ω

Decoupling chokes 1 kHz:

20 mH nominal

Pulse:

1.2/50 μs pulse

Max pulse voltage:

6.6 kV

Series resistor:

2 x 40 Ω, 6 W

Coupling adapters:

INA 170 spark gap device, 90 V trip voltage

INA 171 capacitor 0.1 μF//spark gap device, 90 V trip voltage

INA 174 capacitor 0.5 μF
