A d v a n c e d Te s t S o l u t i o n s f o r E M C
Technical specifications
Teseq AG
Nordstrasse 11F 4542 Luterbach Switzerland
T + 41 32 681 40 40 F + 41 32 681 40 48
[email protected]
www.teseq.com
eft/burst coupling network
cdn 163
691-047A January 2010
EUT (supply) voltage:
690 VAC, line-to-line and line-to-ground
1000 VDC, line-to-line and line-to-ground
EUT current (AC or DC):
≥100 A continuous
150 A for approx. 30 min
EFT/burst pulse peak voltage:
Up to 8000 V
Leakage current to ground:
7.1 mA max. (short duration – during power up)
Terminals:
Screw terminals, 50 mm² rated for 150 A
Temperature monitoring:
Bimetal-thermometer -0 to +120°C
Grounding:
4 mm combined banana and screw terminal (safety
grounding). Via housing bottom plate and brackets
(FH ground to test setup ground plate).
Dimensions L x W x H:
380 x 150 x150 mm (15 x 5.9 x 5.9“)
Weight:
4.2 kg (9.3 lbs) approx.
EFT/burst coupling network options: INA 163: safety banana plug set 6 to 4 mm (10 pcs)
INA 164: Measuring adapter incl. 5 pcs safety banana plugs
CAS 3025: Burst calibration set
