Mains supply options ProfLine 2145-208 ProfLine 2145-400
System contents NSG 1007-45-208 Power source NSG 1007-45-400 Power source
CCN 1000-3 3-phase CCN 1000-3 3-phase
coupling unit coupling unit
DAQ card DAQ card
Interface cable Interface cable
WIN 2106 H&F test WIN 2106 H&F test
software >16 A software >16 A
WIN 2145 PQT test software WIN 2145 PQT test software
Pre-configured PC Pre-configured PC
USB cable USB cable
Power source (for full specification see separate datasheet)
Power output (AC mode)
3 x 15,000 VA 3 x 15,000 VA
Voltage AC, two ranges 0-150 V and 0-300 V 0-150 V and 0-300 V
Maximum current @150 V 100 Amps/phase, 240 Amps 100 Amps/phase, 240 Amps
(low range) peak repetitive peak repetitive
Maximum current @120 V 125 Amps/phase, 300 Amps 125 Amps/phase, 300 Amps
[See constant power graph below] peak repetitive peak repetitive
Maximum current @300 V 50 Amps/phase, 120 Amps 50 Amps/phase, 120 Amps
(high range) peak repetitive peak repetitive
Maximum current @230 V 62 Amps/phase, 150 Amps 62 Amps/phase, 150 Amps
[See constant power graph below] peak repetitive peak repetitive
Frequency range (AC mode) 16 – 819 Hz 16 – 819 Hz
Power output (DC mode) 10,000 watts/phase 10,000 watts/phase
Voltage DC, two ranges 0-200 V and 0-400 V 0-200 V and 0-400 V
Maximum current (low Range) 50 Amps 50 Amps
Maximum current (high Range) 25 Amps 25 Amps
Supply 3-phase, 208 Vac L-L, 50/60 Hz 3-phase, 400 Vac L-L, 50/60 Hz
Dimensions (per chassis) 1270 x 731 x 876 mm (HxWxD) 1270 x 731 x 876 mm (HxWxD)
Weight 522 kg 522 kg
Coupling unit
Number of phases 3 3
Measurement channels 12 12
EUT connector: Rear panel Terminal block Terminal block
Maximum voltage 300 Vac 300 Vac
Maximum current 74 Arms (200 A Pk for 10 ms) 74 Arms (200 A Pk for 10 ms)
Supply power: Voltage 115/230 Vac +/- 10% 115/230 Vac +/- 10%
Technical information
45 kVA 3-phAse hArmonics And flicker
meAsuring system
profline 2145
