Technical specifications
Description: Compact ESD simulator with microprocessor based, large touch-
sensitive LCD panel, built-in HV relay for contact-discharge, mains
operation
Basics: Discharge pistol, high voltage base unit, mains power supply
adapter, (100 to 250 VAC), discharge network 150 pF/330 Ω, air-
and contact-discharge tips, grounding cable, user manual
Pulse data: Standard: Conforms to IEC/EN 61000-4-2 (2001)
Special: Interchangeable networks for other standards
Pulse networks: Network 150 pF/330 Ω as per IEC/EN 61000-4-2 (included)
Optional ISO 10605 networks 330 pF/330Ω 150 pF/2 kΩ and
330 pF/2 kΩ
Range of RC-networks for other standards:
R = 0 Ω to 20 kΩ
C = 50 to 2000 pF
Discharge: Air-discharge: 200 V to 30 kV (in 100 V steps)
Contact-discharge: 200 V to 30 kV (in 100 V steps)
Discharge tips: Ball and point as per IEC and specials; exchangeable by threaded
cap
Charging voltage measurement: kV, accuracy better than ±5% (stabilized)
Discharge detection:
Air-discharge only: indicated by the kV symbol being displayed in
inverse, also acoustically in the single‘s operating mode.
Threshold level on/off.
Holding time: > 5 s (charging voltage ±5%)
Charge resistor: 50 MΩ
Triggering: Trigger button in hand-grip
Operation: Via touch panel and microprocessor
Discharge modes: Air-discharge/contact-discharge
Polarity: Positive, negative/automatic change
Operating modes: Single/repetitive, Pulse counter 0 to 9999
Pre-select counter 0 to 9999
Repetition:
- 0.5/1/5/10/20 or 25 Hz (air)
- 0.5/1/5/10 or 20 Hz (contact)
- Continuous operation
Auto-shut-off: After 15 minutes idle time (without loss of the test parameters)
Display: LCD panel showing: charging voltage, breakdown event, polarity,
air-/contact-discharge, counter/preselect counter content
Weight: Discharge pistol (w/o cable): 1.2 kg (2.6 lbs) approx.
Base unit: 5.7 kg (12.6 lbs) approx.
Ambient conditions: Operation:
+5 to +40°C
20 to 80% r.h. (non-condensing)
