LINE IMPEDANCE STABILIZATION NETWORKS
Current Inductance Line/Ground Voltage Case
Type Number Amps H 50-60 Hz 400 Hz Size* Circuit Frequency Range
6516-5-TS-10-BNC 10 5 270 130 #5 Single 150 KHz- 65 MHz
6516-57-TS-10-BNC 10 57 270 130 #6 Single 14 KHz- 4 MHz , 0.1f coupling capacitor
8012-50-R-24-BNC 24 50 135 N/A #1 Dual 10 KHz- 50 MHz , 0.1f coupling capacitor
8028-50-TS-24-BNC 24 50 270 130 #1 Single 10 KHz- 50 MHz
8116-50-PJ-100-N 100 50 270 130 #3‡ Single 10 KHz- 30 MHz
8116-50-TS-100-N 100 50 270 130 #3‡ Single 10 KHz- 50 MHz
8309-5-PJ-100-N 100 5 500 240 #3 Single 150 KHz- 65 MHz
8309-5-TS-100-N 100 5 500 240 #3 Single 150 KHz- 65 MHz
8328-50-PJ-50-N 50 50 270 130 #3 Single 10 KHz- 30 MHz, 0.1f coupling capacitor
8328-50-TS-50-N 50 50 270 130 #3 Single 10 KHz- 50 MHz, 0.1f coupling capacitor
8410-250-R-24 24 250 270 130 #1 Dual 250H choke network with AC receptacle for use
with 8012-( ) and 9252-( ) for VDE applications
8602-50-PJ-50-N 50 50 270 130 #4 Single 10 KHz- 30 MHz w/ 250H choke
8602-50-TS-50-N 50 50 270 130 #4 Single 10 KHz- 50 MHz w/ 250H choke
8610-50-PJ-100-N 100 50 500 240 #3‡ Single 10 KHz- 30 MHz
8610-50-TS-100-N 100 50 500 240 #3‡ Single 10 KHz- 30 MHz
8611-50-TS-10-N 10 50 270 130 #2 Single 10 KHz- 30 MHz w/ 250H choke
8615-2-TS-100-N 100 2 270 130 #1 Single 1 MHz- 1 GHz , 0.1F coupling capacitor
8616-5-PJ-200-N 200 5 270 130 #3‡ Single 150 KHz- 65 MHz
8616-5-TS-200-N 200 5 270 130 #3‡ Single 150 KHz- 65 MHz
8616-50-PJ-200-N 200 50 270 130 #3‡ Single 10 KHz- 30 MHz
8616-50-TS-200-N 200 50 270 130 #3‡ Single 10 KHz- 50 MHz
8902-5-TS-500-N 500 5 500 240 #4 Single 150 KHz- 1 GHz
*Case Sizes (w x h x l) #3: 10.37" x 9.12" x 13" (26.35 cm x 23.18 cm x 33 cm)
Add 3" (7.62 cm) for Base Plate #4: 7.53" x 7.63" x 18.97" (19 cm x 19.43 cm x 48.26 cm)
‡ With 50 or 60 Hz Ventilating Fan; add 7.09" (18.00 cm) #5: 3.12" x 1.75" x 3.87" (7.94 cm x 4.44 cm x 9.84 cm)
#1: 5.12" x 5.12" x 10" (13 cm x 13 cm x 25.4 cm) #6: 2.75" x 2.45" x 5.7" (6.98 cm x 6.22 cm x 14.48 cm)
# 2: 7.0" x 7.0" x 8.25" (17.78 cm x 11.78 cm x 24.13 cm) #7: 13.37" x 7.25" x 13.25" (33.97 cm x 18.41 cm x 33.65 cm)
Note: Unless otherwise specified, 5µH LISN’s have 0.1f coupling caps; 50µH have 0.25f coupling caps
