Environmental
Temperature –
Operating: 0° C to +45° C.
Non-operating: –20° C to +60° C.
Humidity – 95% RH, non-condensing.
EMI Emissions –
EN55011 class A.
EN60555-2.
Power
Battery Operation –
Battery Type: Six AA Alkaline.
Operating Time: >4.5 hrs. with backlight off.
Battery Saver: Selectable for 5 to 30 minutes
or disabled.
Physical
Dimensions mm
in.
Height
141
5.6
Width
211
8.3
Depth
43
1.8
Weight kg
lb.
Net
1
2.2
TelScout TS90
Includes: Test Leads (two pair), Carrying
Case, Alkaline Batteries (six), User Manual.
TS90 OPTIONAL ACCESSORIES
Rechargeable NiCad Battery Pack –
THM5BAT.
External Charger for NiCad Battery Pack –
THM5CHG.
Includes: DC Adapter, Charger Pedestal, and
one of following wall transformers (specify
when ordering):
Standard – 110 V US.
Opt. A1 – 220 V Universal Euro.
Opt. A2 – 240 V UK.
Opt. A3 – 240 V Australia.
Opt. A6 – 110 V Japan.
Strand Hook (D-Ring) – 354-0745-00.
Service Manual – 071-0095-00.
LANGUAGE OPTIONS
Standard – English.
Option L1 – French.
Option L4 – Spanish/Portuguese (Spanish
default).
Option L6 – Portuguese/Spanish (Por-
tuguese default).
Option LC – Czechoslovakian.
Option LD – Dutch/French (Dutch default).
Option LF – Finnish.
Test Signal Output – 1/2 Sine, balanced.
Amplitude –
≤6 V into 105 Ω.
Output Impedance – 105
Ω nominal.
Pulse Widths – 5 ns to 2,500 ns (auto-
matic).
Input Protection – ±200 V, DC + peak AC, to
a maximum of 440 Hz.
Maximum Range – 15,000 m (45,000 ft.)
depending on cable type and condition.
Cursor Resolution – 0.4% of selected
range.
Display – 5.25-in. high-contrast, high-
resolution, backlit LCD, 520 x 200 pixels.
Display Ranges – Eleven automatic display
ranges plus single-button expand window.
Filter – High pass, cutoff frequency
150 kHz, user selectable.
Amplifier – 5 mV reflection produces a full-
screen vertical deflection.
Gain – 0 to 63 dB.
Horizontal Design Accuracy –
0.01% ± 300 ps ± Vp uncertainty ± cursor
resolution.
TelScout
TS90
Characteristics
General
Characteristics
Ordering
Information
2/01
TD/XBS
22W–11853-0
