V4 Performance Specifications
AC Hipot
Voltage Range: 100 to 5000 VAC RMS
Voltage Setting Resolution: 5V/step
Voltage Regulation: 1% of reading + 5V
Voltage Accuracy: 1% of reading + 10V
Voltage Monitoring: At Output Terminals
Output Current: 30mA to 40mA 180S max,
0 to 30mA continuous. Below 500V 10mA max
Min/Max Current Limits: 0.1 to 40mA
Current Accuracy: 1% of reading + 50µA
DC Hipot
Voltage Range: 100 to 6000 VDC
Voltage Setting: Resolution: 5V/step
Voltage Regulation: 1% of reading + 5V
Voltage Accuracy: 1% of reading + 10V
Voltage Monitoring: At Output Terminals
Max Output Current: 10mA continuous, below
500VDC 2mA continuous
Min/Max Current Limits: 0.01 to 10mA
Current Accuracy: 1% of reading + 50µA
Insulation Resistance
DC Output Voltage: 50, 100, 500 or 1000V
Resistance Range: 1 to 9999M
Ω
Resistance Accuracy: (% of reading)
50, 100 VDC 1-50MO 5%
51-200MO 10%
201-1999MO 20%
500, 1000
VDC 1-500MO 5%
501-2000MO 10%
2001-9999MO 20%
Multi-Mode IR™: Select 1 of 3 modes - test
passes on good reading, test fails on bad reading,
pass/fail determined at end of test time.
Ground Bond / Continuity
Test Current: 3A to 40 amps RMS
Terminal Configuration: 4 wire Kelvin
Resistance Range: 0 to 600m
Ω
Resistance Resolution: 100µ
Ω
Resistance Accuracy: 1% reading ±3m
Ω
Compliance Voltage : 8 volts at terminals
Current Resolution: 0.01A
Voltage Resolution: 0.01V
General
Test Database: 10 test sequences, up to 16
steps each with up to 6 steps per test sequence
Front Panel Lockout: Prevents database edit
while in lockout mode
Arc Detect: 10 level trip select
Remote Interfaces: Fully interactive RS232, -
PLC interface, scanner control port – all standard
talk/listen GPIB interface - option GP-V4
Timer Accuracy: 0.25%
±
50mS
Power Source: AC100V, 120V, 220V,
230V (±10% 50/60Hz), 350W max
Operating Environment: Indoor use, altitude up
to 6500ft (2000m). installation category II.
Pollution Degree 2
Operating Temperature: 0°C to 40°C, 80% RH
Storage Temperature: -10°C to 70°C, 70% RH
Dimension: 17.6”L x 13”W x 5.9”H,
446(L) x 330(W) x 149(H)mm
Weight: 33lbs (15kg) net, 40 lbs (18 kg) ship
Accessories: NIST cal cert, TL-2050 & K-2 test
leads, instruction manual and power cord
Accuracy: Stated specifications apply for 1
year at 23
°
C
±
5
°
C
Calibration: ANSI/NCSL Z540 Certificate of
calibration with data provided, traceable to NIST
Compliance: CE mark certified to EN61010
and EMC directives EN50081-1 & EN50082-2
Warranty: 3-Year extended warranty with annual
factory calibration, 1 year parts and labor
standard
QuickTest

Software
Option QT-V4: Bundled test automation software
and PC serial interface cable. Easy to load
graphical test sequence development and
operating environment. Provides time/date,
operator, test parameters, test results and
readings. Results may be viewed, printed out or
exported to a database program.
Ordering Information
V4 Four-in-1 Electrical Safety Tester
GP-V4 GPIB Interface Option
QT-V4 Bundled Quicktest Software with Serial
Cable
TL-115-4 Hipot/GB Outlet Test Adaptor
TL-1050 High Volt Probe Lead Set
TL-2050 High Volt Alligator Lead Set
TL-IEC4 IEC Socket Lead Set
K-2 High Current, 4-wire,2 Clip Kelvin Lead Set
K-4 High Current, 4-wire, 4 Clip Kelvin Lead Set
RPO-4 Rear Panel Output Terminals
RM-4 Rack Mount Kit
Represented By:
Vitrek Corporation
9880A Via Pasar
San Diego, CA 92126
For more information call:
858 689 2755 or Email
[email protected]
Specifications subject to change without notice.
