M O D E L 9 1 1 0 D
SPECIFICATIONS:
G
ENERAL
:
Frequency Range (operating, 100 gram payload) 7 Hz to 10 kHz
420 to 600000 CPM
Maximum Amplitude (100 Hz, with no payload) 20 g pk (196 m/s 2 pk)
15 in/s pk (380 mm/s pk)
50 mils p-p (1270 µm p-p)
Maximum Payload [1] 800 gram
A
CCURACY OF
R
EADOUT
:
Acceleration (30 Hz to 2 kHz) ± 3%
Acceleration (7 Hz to 10 kHz) ± 1 dB
Velocity (10 Hz to 1000 Hz) ± 3%
Displacement (30 Hz to 150 Hz) ± 3%
Amplitude Linearity (100 gram payload, 100 Hz) < 1% up to 10 g pk
Waveform Distortion (100 gram payload, 30 Hz to 2 kHz) < 5% THD (typical) up to 5 g pk
U
NITS OF
R
EADOUT
Acceleration g pk, g RMS, m/s 2 pk, m/s 2 RMS
Velocity mm/s pk, mm/s RMS, in/s pk, in/s RMS
Displacement mils p-p, µm p-p
Frequency Hz, CPM
I
NPUT
/O
UTPUT
Test Sensor In Voltage or ICP ®
Bias Fault Indication (ICP ® Sensors) Yes
External Source In (Max) 1V AC RMS
Monitor Reference Out 10 mV/g (nominal), buffered internal reference
P
OWER
R
EQUIREMENTS
Internal Battery (sealed solid gel lead acid) 12V DC, 4 amp hours
AC Power (for recharging battery) 110-240V, 50-60 Hz
Operating Battery Life [2]
100 gram payload, 100 Hz, 1 g pk 18 hours
100 gram payload, 100 Hz, 10 g pk 1 hour
M
EMORY
Size Up to 500 calibration records
Points Per Record 30 calibration data points
Sensor Information Model number, serial number, sensitivity direction
(x, y, z), user notes
USB Port Export to flash drive (FAT32)
Export File Format CSV (comma-separated values)
P
HYSICAL
Dimensions (H x W x D) 22 cm x 30.5 cm x 28 cm (8.5 in x 12 in x 10 in)
Weight 8.2 kg (18 lb)
Sensor Mounting Platform Thread Size 1/4-28
Operating Temperature 0°C-50°C (32°F-122°F)
A
CCESSORY
P
OUCH
I
NCLUDES
O
PTIONAL
A
CCESSORIES
PD-1320-01: Mounting Wrench 9100-MNTKIT: Mounting Accessory Kit
9100-PS01: Universal Power Supply and Plug Adaptors 9105C: Transfer Standard Reference Accelerometer
081B20:
1/4-28 to 1/4-28 Adaptor
9100-MPPA01: Proximity Probe Adaptor Kit (Metric)
081A08: 10-32 to
1/4-28 Adaptor
9100-PPA01: Proximity Probe Adaptor Kit
080A118: Mounting Pad For Sensor With a Magnet Base 9100-PPA02: Target for Proximity Probe (AISI 4140)
9110-USB: USB Flash Drive with Report Generation Worksheet
[3]
9100-PS01: 18V DC, 1 Amp Power Supply/Charger
[1] Operating range reduced at higher payloads. Reference manual for full details.
9100-BAT01: Replacement Battery
[2] As shipped from factory in new condition.
[3] Microsoft Excel required.
DS-0103 rev A
