MODEL 5263
0.7 - 4.2 GHz
60 WATTS
LINEAR POWER RF AMPLIFIER
5300 Beethoven Street, Los Angeles, CA 90066
TEL: (310)306-5556 FAX: (310)821-7413
WEB: www.ophirrf.com E-MAIL: [email protected]
RFPA SYSTEM OPTIONS
◊ Switched Filter Bank
◊ Input Power Requirements
◊ Ruggedized Version
◊ Cabinet Requirements
◊ Outdoor Version
◊ Sample Ports
◊ Racking Options
◊ Many More!
◊ Consult Factory with Specific Requirements
CIRCUIT CONTROL
(WITH FRONT PANEL CONTROLLER)
◊ Standby (amplifier disable)
◊ Gain/power setting with 20dB range
◊ VSWR protection Reset
◊ ALC On/ Off
FRONT PANEL CONTROLLER FEATURES
◊ Forward Power Monitoring
◊ Reflected Power Monitoring
◊ Gain Control (Continuously Variable VVA 20dB)
◊ Fault Status
◊ Full Protection Of any VSWR Condition, Open or Short, into any Phase Angle
◊ Remote Control Access via the Ethernet, RS-232, or IEEE-488 Communications
ports
◊ Integrated Automatic Leveling Control to allow end-user to maintain output even with
variances in temperature, phase or input RF level
◊ Standby/Enable Control
◊ Front Panel Display for easy viewing of System Status Locally
◊ Keypad buttons for full local control
CIRCUIT PROTECTIONS
◊ Thermal Overload
◊ Over Current
◊ Over Voltage
◊ Open or Short VSWR Conditions (
With Front Panel Controller )
CIRCUIT INDICATIONS
(WITH FRONT PANEL CONTROLLER)
◊ Forward Power
◊ Reflected power
◊ VSWR Fault
◊ Temp Fault
◊ Gain Setting (VVA) percentage
04/12 Approved By: ________________________________________________ Date: _____________________
