5000 Series Specifications
General Information
H
all E
ffe
ct
Ga
u
s
s
m
e
ter
s
Bell Technologies Inc. a SYPRIS company • 6120 Hanging Moss Road • Orlando, Florida 32807 • Tel.: (407) 678-6900 • Fax: (407) 677-5765 • www.fwbell.com
Due to continuous process improvement, specifications subject to change without notice.
Probes
and Accessories
Model
5060
5070
5080
Basic Accuracy
4%
2%
1%
Frequency Bandwidth
dc
dc - 10 kHz
dc - 20 kHz
Sampling Rate (dc Mode)
10/sec
10/sec
10/sec
Ranges
Low Range
Mid Range
High Range
(2)
2 kG
-
20 kG
(3)
200 G
2 kG
20 kG
(3)
300 G
3 kG
30 kG
Resolution
Low Range
Mid Range
High Range
1.0 G (100
mT)
-
10 G (1 mT)
0.1 G (10
mT)
1.0 G (100
mT)
10 G (1 mT)
0.1 G (10
mT)
1.0 G (100
mT)
10 G (1 mT)
Display
LCD
LCD
LCD
Digits
3 ‰
3 ‰
3
Readings
Gauss
Tesla
Gauss
Tesla
Ampere / Meters
Gauss
Tesla
Ampere / Meters
Analog Output
-
-
±3V F.S.
Communication Port
-
-
RS-232
Model
All
Temperature
Operating
Storage
0
°C to +50°C
Power
two 9V batteries
Size
Length x Width x Height
5.2 (132 mm) x 5.3 (135 mm) x 1.5 (38 mm)
Model Number
Description
Item Number
Model 5080 Probes
STD58-0404
STD58-0402
SAD58-1904
SAD58-1902
4 Transverse Probe (Std. w meter)
2 Transverse Probe
4 Axial Probe
2 Axial Probe
125804
125803
125802
125801
Model 5070 Probes
STH57-0404
STH57-0402
SAH57-1904
SAH57-1902
4 Transverse Probe (Std. w meter)
2 Transverse Probe
4 Axial Probe
2 Axial Probe
125704
125703
125702
125701
Model 5060 Probes
HTV56-0602
STV56-0404
STV56-0402
SAV56-1904
SAV56-1902
2 H.D. Transverse Probe (Std. w meter)
4 Transverse Probe
2 Transverse Probe
4 Axial Probe
2 Axial Probe
125605
125604
125603
125602
125601
Meter Accessories
X-5000-0006
YA-111
PSU-15
PSR-15
6 ft. Extension Cable
Zero Gauss Chamber
AC Adapter, 110V
AC Adapter, Switching
125000
122920
145012
115001
Due to contin
uous process improvement, specifications subject to change without notice.
-25ºC to +70ºC
®
1
/2
1/2
3/4
6120 Hanging Moss Road • Or
lando, Florida 32807
Phone (407) 678-6900 • Fax (407) 677-5765 •
