Type
TC/VDE
Type TC/IEC
Type TC/DE
Type TC/BS
TYpE TEST STANDARD TEST ELECTRODES GAp SETTING RATE OF RISE
TC/DE Polished brass disc .1”
(flat electrodes) 1” (25 mm) diameter +/-0.0005”
TC/VDE Spherical dome .04” or .08”
(motorized with stirrer) 1.4” (36 mm) diameter +/-0.001”
Spherical dome 2.5 mm
36 mm (1.4”) diameter +/-0.1 mm
Spherical cap 2.5 mm
12.5 mm (.5”) diameter +/-0.1 mm
TEST CELLS
ASTM D877
ASTM D1816
IEC 60156
BS 148
TC/IEC
TC/BS
3000 Volts per Second
500 Volts per Second
2000 Volts per Second
2000 Volts per Second
IN
pUT
OUT
pUT
RATE
OF RISE
DUTY
CYCLE
DIMENSIONS
& WEIGHTS
SHI
pp
ING
SIZE
DIGITAL MEMORY VOLTMETER
Voltage / Current
selectable
Frequency
MODEL LD60 LD75 LD100
120 V, 5 A 120 V, 5 A 120 V, 5 A
230 V, 2.5 A 230 V, 2.5 A 230 V, 2.5 A
50 or 60 Hz
(Voltage and frequency required must be specified)
Voltage 0-60 kV at 500 VA 0-75 kV at 500 VA 0-100 kV at 500 VA
Maximum Voltage to Earth 30,000 V 37,500 V 50,000 V
500/2000/3000 2000 Volts per Second, 2000 Volts per Second,
Volts per Second Variable Variable
continuous breakdown testing
Range ~0-60 kV ~0-75 kV ~0-100 kV
Accuracy +/-1% of Full Scale +/-1% of Full Scale +/-1% of Full Scale
Length 21.25” (540 mm) 30” (762 mm) 36” (914 mm)
Width 16.75” (426 mm) 18” (457 mm) 20” (508 mm)
Height 13.75” (350 mm) 13” (330 mm) 16” (406 mm)
Weight 51 lbs (23 kgs) 120 lbs (54 kgs) 135 lbs (61 kgs)
Length 24” (610 mm) 40” (1016 mm) 40” (1016 mm)
Width 21” (533 mm) 30” (762 mm) 30” (762 mm)
Height 18” (457 mm) 32” (813 mm) 32” (813 mm)
Weight 63 lbs (29 kgs) 220 lbs (100 kgs) 230 lbs (104 kgs)
OpTIONS
Liquid Dielectric
Comparison Unit
The LDCU is an AC voltmeter
which is used to make periodic
performance checks of the
system. See LDCU data sheet
for more details.
