Atec Phenix-600 Series - Manual (Page 2)

• Burn Feature
The Burn Feature is a current limiting device that
is connected in series with the primary winding.
This feature offers the ability to burn the faults in
the test specimen at a controlled current level.
The Burn Feature is available with a rating from
25-100% of rated current.
• Flashing light
• Digital Meters (3 1/2 digit lcD display)
• latching HV On/Off pushbuttons
• Dwell Timer
• casters mounted on cabinets
• custom cable lengths
DiMenSiOnS & WeigHT / SHipping SiZe – consult factory
inp
UT
OUT
pUT
DUTY cY
cle
S
MODel 610-5p 610-10p 610-20p 615-7.5p 615-20p
Voltage 220/240 V 220/240 V 220/240 V 220/240 V 220/240 V
Frequency 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Voltage ≈ 0-10 kV ≈ 0-10 kV ≈ 0-10 kV ≈ 0-15 kV ≈ 0-15 kV
Current 0-500 mA 0-1 A 0-2 A 0-500 mA 0-1.33 A
5 min ON/15 min OFF 5 kVA 10 kVA 20 kVA 7.5 kVA 20 kVA
inp
UT
OUT
pUT
DUTY cY
cle
S
MODel 603-2p 605-2p 605-5p 605-10p 610-2p
Voltage 115/120 V, 60 Hz 115/120 V, 60 Hz 220/240 V 220/240 V 115/120 V, 60 Hz
or or or
Frequency 220/240 V, 50 Hz 220/240 V, 50 Hz 50/60 Hz 50/60 Hz 220/240 V, 50 Hz
Voltage ≈ 0-3 kV ≈ 0-5 kV ≈ 0-5 kV ≈ 0-5 kV ≈ 0-10 kV
Current 0-667 mA 0-400 mA 0-1 A 0-2 A 0-200 mA
5 min ON/15 min OFF 2 kVA 2 kVA 5 kVA 10 kVA 2 kVA
OpTiOnS
SAFeTY & DeSign FeATUReS
• One-piece design
• Circuit breaker protection
• External interlock provision
• HV On momentary pushbutton with indicator
• Zero Start Interlock
• Manual control of output voltage
• Adjustable overload circuit
• Slow and fast-acting transient protection on all
meters and relays
• Analog multi range metering
• Emergency Off pushbutton (5-20 kVA models only)
• Output overload indicator with reset switch
• Input power cable 5’ (1.5 m) and shielded output
cable 15’ (4.5 m) are included
• Two copies of operation/maintenance manual
enViROnMenTAl cOnDiTiOnS
• 10-40°C, indoor/outdoor in fair weather
• Humidity <95% non-condensing
• Altitude <3000 ft (1000 meters)
