Detailed Specifications
2 Fluke Corporation Ti55FT and Ti50FT Thermal Imagers with IR-Fusion
Detailed specifications
Fluke Ti55FT Fluke Ti50FT
Imaging performance
Field of view (FOV)* 23° horizontal x 17° vertical
Spatial resolution (IFOV)* 1.30 mrad
Min focus distance* 0.15 m (5.9 in)
Thermal sensitivity (NETD) ≤ 0.05 °C at 30 °C (50 mK) ≤ 0.07 °C at 30 °C (70 mK)
Detector data acquisition/image
frequency
60 Hz/60 Hz
Focus SmartFocus; one finger continuous focus (manual)
IR digital zoom 2x, 4x, 8x 2x
Detector type 320 x 240 Focal Plane Array, Vanadium Oxide (VOx) Uncooled Microbolometer
Spectral band 8 µm to 14 µm
Digital image enhancement Automatic full time enhanced
On camera operating modes Full thermal, full visual light or merged
thermal-visual images.
Picture-in-Picture
Visible light camera 1280 x 1024 pixels, full color
Visible light digital zoom 2x, 4x 2x
Temperature measurement
Calibrated temperature range -20 °C to 600 °C (-4 °F to 1112 °F)
in three ranges
Range one =-20 °C to
100 °C (-4 °F to 212 °F)
Range two = -20 °C to
350 °C (32 °F to 662 °F)
Range three = 250 °C to 600 °C
(482 °F to 1112 °F)
-20 °C to 350 °C (-4 °F
to 662 °F) in two ranges
Range one = -20 °C to
100 °C (-4 °F to 212 °F)
Range two = -20 °C to
350 °C (32 °F to 662 °F)
Accuracy ± 2 °C or 2 % (whichever is greater)
Measurement modes Centerpoint, center box (area min/max, average),
moveable spots/boxes, user defined field/text
annotations, automatic hot and cold point
detection, visible color alarm above and below
Centerpoint, center box
(area min/max, average)
Emissivity correction 0.1 to 1.0 (0.01 increments)
Image presentation
Digital display 13 cm (5 in) diagonal large high-resolution digital display
LCD backlight Sunlight readable color LCD
Video output RS170 EIA/NTSC or CCIR/PAL composite video
Palettes Grayscale, grayscale inverted, blue red, high contrast, hot metal,
ironbow, amber, amber inverted
Optical lenses
54 mm telephoto lens High precision Germanium lens
Field of view (FOV): 9° horizontal x 6° vertical
Spatial resolution (IFOV): 0.47 mrad
Min focus distance: 0.6 m (1.97 ft)
10.5 mm wide angle lens High precision Germanium lens
Field of view (FOV): 42° horizontal x 32° vertical
Spatial resolution (IFOV): 2.45 mrad
Min focus distance: 0.3 m (0.98 ft)
*Standard 20 mm Germanium lens
