SPECIFICATION
MECHANICAL
Housing:
Die-cast aluminium box
Dimensions:
100mm x 100mm x 60mm
(excluding handle)
Weight:
≤
1.3kg including battery
Mounting:
Hand held and tripod mount
FEATURES
•
Multiple image storage and retrieval capability.
•
Temperature data logging.
•
Image browser.
•
Readout in
o
C,
o
F or K.
•
Battery charge indicator – Pocket PC
•
Pocket PC controlled by direct navigation/action buttons.
OPTIONS
•
Light shade for operation in bright sun light.
•
Extension lead: Imager to Pocket PC
IMAGER POWER SUPPLY
Battery:
Included
Battery life Imager:
≥
8 hrs.
Charger:
Supplied
PERFORMANCE
Temperature range:
-20
o
C to +90
o
C
(up to 150
o
C with reduced accuracy)
High temperature option: 600
o
C
(up to 1000
o
C with reduced accuracy)
Field of view: 20
o
x 20
o
(optional
10
o
x 10
o
)
Spectral Response:
8 to 14 micrometres
Temperature sensitivity: ~0.5K
@ 30
o
C
Temperature readout: all pixels via
moveable cursor
Displayed image:
up to 128 x 128 pixels
Detector:
16 x 16 pixel array
Frame integration:
up to ten frames
Frame rate:
6 Hz.
COMPUTER INTERFACE
2m cable for connection to PC serial port is supplied.
SETTINGS AND CONTROLS
Power on/off switch on imager box.
All functional controls set via dialogue boxes on computer:
•
User selectable sensitivity settings.
•
User selectable temperature offset control (range).
•
User defined emissivity values.
•
Pixel integration options to improve the temperature sensitivity.
•
Image display may be selected to be in a variety of colours or
greyscale.
•
User selectable spatial interpolation to improve visual presentation
of data.
LASER POINTER
A built in Class 2 laser is supplied to highlight the
reference pixel.
COMPUTER REQUIREMENTS
Compaq iPAQ H3600 series colour Pocket PC supplied.
If used with an IBM compatible PC, the following
minimum specification is required:
32Mb RAM
300 MHz processor
MS Windows 95 and 98, NT, 2000
RS232 serial port (115k Baud)
24 bit colour graphics capability
If a laptop computer is used, a TFT display is
recommended.
ENVIRONMENT (IMAGER)
IP rating:
52 (does not include Compaq iPAQ)
Temp. operating range:
-5
o
C to + 50
o
C
Humidity:
10% to 95% non condensing
Temp. storage range:
-20
o
C to +80
o
C
CE Mark:
Complies with EMC directive
Whilst IRISYS Ltd. endeavour to ensure that all descriptions, weights, temperatures, dimensions and other statistics contained in this product information are correct,
they are intended to give a general idea of the product only and IRISYS do not warrant their accuracy or accept liability for any reliance on them. IRISYS Ltd. have a
policy of continuous product improvement and reserve the right to change the specification of the products and descriptions in this data sheet. Prior to ordering
products please check with IRISYS for current specification details. This product is protected by patents EP 0 853 237 B1 and US 6,239,433 B1. Other patents
pending
