LanTEK II

Handset Dimensions

Height/Width/Depth: 10in. x 5in. x 2.1in. (25.4cm/12.7cm/5.3cm)

Handset weight w/battery

Display: 2.4lbs/1.1kg; Remote: 2.3lbs/1.0kg

Battery

Lithium ion, 7.4VDC, 6.6AH; Input: 12V/2A DC; Typical operating time: 18 hours (new battery running a Cat6 test every 2.5 minutes, full backlight); Charge time: 4 hours quick

charge with battery removed from handset, 6 hours inside handset.

Input power

Handset: DC 12-15V, 2A; Line/mains power: AC 110-240V, 50/60Hz

Display

4.3” wide screen TFT, 480 x 272 pixel, 95 x 54mm viewable area

Connectivity

Adapter port: 168 pin ultra low crosstalk, mini-USB device port, USB host port (display handset only), four pin serial port (service use only), 1/8” talkset jack, power/charging jack

Frequency range

LanTEK II-350: 1-350MHz, LanTEK II-500: 1-500MHz, LanTEK II-1000: 1-1000MHz

Memory

Non-volatile flash, storage capacity for 1700 TIA-Cat 6 tests with graphs. Tests can be copied to USB flash drive, up to 64GB.

Measurements

Wire map, DC loop resistance length, capacitance, NEXT, insertion loss (formerly attenuation), ACR-N (formerly ACR), return loss, average impedance, propagation delay, delay

skew, power sum NEXT, power sum ACR-N (formerly power sum ACR), ACR-F (formerly ELFEXT), power sum ACR-F (formerly power sum ELFEXT), alien crosstalk (with optional

AXT testing kit)

Length measurement

0-2000 ft.; 1 ft. resolution, +/-(3% + 3 ft.), distance to short/open reported

Supported cable types

TIA/EIA Category 3, 4, 5, 5E, 6 and 6A: 100Ω

ISO/IEC Class C, D, E, EA, F, FA: 100Ω

Cat 6/6A Class E/EA RJ-45 permanent link adapters: shielded and un-shielded cable, universal adapters provide channel, permanent link and basic link measurements.

Supported connectors

Additional adapters: GG45, ARJ45, TERA, EC7 (MMCPRO3000), Coax 50-75Ω (BNC connector), M12 industrial

Tone generator

Integrated into display and remote handset, compatible with standard analog inductive probes, selectable tone (high/low/warble) 500/600 Hz, selectable pin output.

Input protection

100V @ 25mA

Operating temperature

0°C to 50°C, non-condensing

Storage temperature

-20°C to 70°C, non-condensing

Vibration/shock

MIL-PRF-28800 F, Class 3

Supported languages

Chinese, Czech, Danish, Dutch, English, French, German, Italian, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish

Accuracy

Baseline: Certified by ETL to meet IEC 61935 Level III/IIIe/IV; Channel/Permanent link: TIA 568-B.2-2 and IEC 61935 Level III/IIIe/IV

Warranty (LanTEK II/FiberTEK

FDX)

One (1) Year from date of purchase

Batteries and accessories are warranted 90 days from date of purchase

PC Software

Requirements: Microsoft Windows

XP or Vista, (32/64 bit) 512MB RAM, 500MB hard disk + 1GB for every 1,500 Category 6 tests

FiberTEK FDX

Compatability

LanTEK

II (any model)

Connector

User changeable adapter (SC, FC, ST), 2.5mm ferrule

Laser safety

Multi-mode 850 VCSEL: class 3, 5mW max; multi-mode 1300 laser: class 3, 5mW max; Single mode 1310 & 1550: class: 3, 5mW max

Power meter accuracy

± .5dB from 0dBm to -40dBm 850-1550nm; system dynamic range 40dB

Length accuracy

±3%; maximum distance measurement 3000m

Display resolution

Power/attenuation: 0.1dB, length: 0.1m/0.1ft

Specifications

Specifications subject to change without notice.

Cat. No.

Description

33-991

LanTEK

II-350: TIA/EIA Cat6, ISO Class E certifier w/Cat6 adapters

33-992

LanTEK

II-500: TIA/EIA Cat6A, ISO Class E

certifier w/Cat6A adapters

33-993

LanTEK

II-1000: TIA/EIA Cat7A, ISO Class F/F

certifier w/Cat6A adapters

LANTEK10GBKIT

Alien Crosstalk Testing Kit for 10GbE Certificatioin. Compatible with 33-992 and 33-993.

Contents: LanTEK

II display and remote handset, two smart lithium ion batteries, two 110-240V power adapters with US/EU/UK plugs, lockable semi-rigid carrying case, Cat6A F/FTP patch cords, USB cable,

DataCENTER data management and reporting software, two headsets, hanging straps and ETL accuracy certificate.

33-990-FA01

Multimode (850/1300nm) kit with LED light sources for standard multi-mode fiber, 850nm LED, 1300nm LED

33-990-FA02

Multimode (850/1300nm) kit with VCSEL/laser light sources for laser optimized fiber, 850nm VCSEL, 1300nm FP laser

33-990-FA03

Single mode (1310/1550nm) kit with laser light sources for single mode fiber, 1310nm FP laser, 1550nm FP laser

33-990-FA04

Combination MM/SM kit with LED MM sources and laser SM sources (33-990-FA01 & 33-990-FA03)

33-990-FA05

Combination MM/SM lit with VCSEL/laser MM sources and laser SM sources (33-990-FA02 & 33-990-FA03)

33-993-FA0X

Combination of LanTEK II-1000 and FiberTEK FDX; (Substitute 1 through 5 in place of “X” to indicate fiber option from choices above)

Contents: Two FiberTEK FDX modules, lockable semi-rigid carrying case, SC, FC, ST adapters for modules (2 ea.), SC-SC patch cords (MM kits: 3x 62.5µm, 3x 50µm; SM kits: 3x 9um SMF) compliant to ISO/IEC

14763-3 standard, quick reference guide, and electronic operation manual.
