T-BERD/MTS-2000 PLATFORM

General (typical at 25°C)

Display

5-inch TFT color touch screen (12.5 cm)

Resolution 800 x 480 WVGA

Interfaces

Two USB 2.0 ports

One mini-USB 2.0 port

RJ-45 LAN 10/100/1000 Mbps

Built-in Bluetooth (optional)

Built-in WiFi 802.11 b/g/n (optional)

Internal memory

1 GB (128 MB for storage)

Battery

Rechargeable lithium-polymer battery

8-hour operation as per Telcordia GR-196-CORE

Power supply

AC/DC adapter, input 100-250 VAC,

50-60 Hz; 2.5A max, output 12 VDC, 25W

Electrical safety: EN60950-compliant

Size with module (H x W x D)

175 x 138 x 80mm

(6.9 x 5.4 x 3.2 in)

Weight

with battery

0.864 kg (1.89 lbs)

with battery and LM OTDR

1.21 kg (2.67 lbs)

Temperature

Operating: -20 to +50°C (-4 to 122°F)

Storage: -20 to +60°C (-4 to 140°F)

Relative humidity

0% to 95% non-condensing

Ordering Information

T -BERD/MTS-2000 Handheld Modular Test Set

ETB2000T/ EM2000T

Includes: touch screen, hands-free soft case, shoulder strap, power supply with 5 adaptable plugs (US, Europe, UK, Australia, Japan), one USB cable, one Getting Started manual
Built-in optical power meter and VFL, with 2.5 mm UPP connectors

E20PMVFL

Built-in optical power meter with 2.5 mm UPP connector

E20PM

Built-in visual fault locator (VFL) with 2.5 mm UPP connector

E20VFL

Built-in optical power meter and talk set

E20TSPM

Bluetooth option for T-BERD/MTS-2000 Modular Test Set

E20BLUE

USB2.0 digital video scope kit (P5000i), including 7 tips and soft case

EDFSCOPE5Ki

Soft carrying case for T-BERD/MTS-2000/4000

E40SCASE1

Hard carrying case for T-BERD/MTS-2000 Modular Test Set

E20HCASE

12V car adapter for T-BERD/MTS-2000/4000

E40LIGHTER

Built-In Power Meter Specifications

(1)

Calibrated wavelengths

850/1310/1490/1550/ 1625/1650

Wavelength range

800 to 1650 nm in 1 nm steps

Accuracy

(2)

±0.2 dB

Measurement range

(3)

+5 to −50 dBm

Maximum resolution

0.01 dB/0.01nW

Connector type

Universal push pull (UPP)

(1) At 25°C, after 20 minutes stabilization time and

after zero setting.

(2) At calibrated wavelength (except 1650 nm)

(3) -45dBm from 800 to 1250 nm

Built-In Visual Fault Locator (VFL)

Wavelength

650 nm

Emission mode

CW, 1 Hz

Laser class

Class 2 per standards EN60825-1

and FDA21 CFR Part 1040.10

Built-In Talk Set

Dynamic range

32 dB (typical)

Connector types

SC, FC, and UPP

(three adapters included)

Specifications

StrataSync — Empower Your Assets

StrataSync is a hosted, cloud-enabled solution that provides asset, configuration,

and test-data management of JDSU instruments and ensures that all have the latest

software and options installed. StrataSync manages inventory, test results, and per-

formance data anywhere with browser-based ease and improves technician and

instrument efficiency. StrataSync manages and tracks test instruments, collects and

analyzes results from the entire network, and informs and trains the workforce.
