Smart Aligner Features
Smart Aligner Specifications
Performance
Azimuth accuracy:
0.5º
Tilt and roll accuracy:
0.1º
Position accuracy:
60 cm with SBAS
Start up time:
< 30 seconds
Power
Internal battery:
Rechargeable lithium ion
Operation time:
7 hrs (over 80 alignments)
Battery charger:
AC wall charger and DC car charger
Physical
Smart Aligner Tool (patent pending)
Dimensions:
19”x 4.5”x 3” (48.3 cm x 11.4 cm x 7.6 cm)
Weight:
4 lb (1.8 kg)
Universal Mounting Bracket (patented)
Dimensions:
19”x 5”x 3” (48.3 cm x 12.7 cm x 7.6 cm)
Weight:
5 lb (2.3 kg)
Carrying Case (contains all components)
Dimensions:
21”x 16”x 8.5” (53.3 cm x 40.6 cm x 21.6 cm)
Weight:
12 lb (5.4 kg)
TOTAL WEIGHT
21 lb (9.5 kg)
Communication Ports
LED backlit display:
User interface and display
Wi-Fi:
Smart Aligner to user’s mobile device
Connectivity:
Smartphone/Tablet – iOS or Android
Cable interface:
Serial RS-232
Reporting
Report formats:
JPEG (screenshot), PDF or CSV
Photos:
Embedded in PDF report
Photos can also be used as a backup, by taking a picture of the User Display.
