SPECIFICATIONS
NIM-511 NIM-513
DISPLAY AND FUNCTIONS
Display type Transflective LCD, monochrome, LED backlight
Display size 4 cm (1.5”), 128 x 64 dots
Refresh rate 400 ms
Result display E-field or H-field value (selectable, 4 digits)
Result units mW/cm 2 , W/m 2 , V/m, A/m
Result types (isotropic, RSS)
ACT - displays the actual value
MAX - holds the maximum of the measured values
AVG - displays the 6 min time averaged result
SPATIAL - displays a spatially averaged result
Hold Hold button to freeze the value that is currently displayed
Zeroing Automatic zeroing after power-on and repetitively every 15 min
MEASURING
Field type Electric (E-) field and magnetic (H-) field
Frequency range 300 kHz to 100 MHz 10 MHz to 42 MHz
Measurement range
E-field: 0.1 to 100 mW/cm 2 (20 to 614 V/m)
H-field: 0.2 to 200 mW/cm 2 (0.073 to 2.3 A/m)
CW damage level 50 W/cm 2
Sensor type Two diode based systems for E-field and H-field
Directivity Isotropic (Tri-axial)
Readout mode / spatial assessment Combined 3-axes (RSS)
UNCERTAINTY
Flatness of frequency response
Calibration uncertainty not included
E-field:
±0 dB @ 13.56 MHz
±1.5 dB (300 kHz to 100 MHz)
H-field:
±0 dB @ 13.56 MHz
±0.6 dB (300 kHz to 100 MHz) E-field:
±0 dB @ 27.12 MHz
±1.0 dB (10 MHz to 42 MHz)
H-field:
±0 dB @ 27.12 MHz
±0.6 dB (10 MHz to 42 MHz)
Calibration uncertainty ±0.5 dB
Linearity
Referred to 10 mW/cm²
±1 dB (0.5 to 2 mW/cm²)
±0.5 dB (2 to 100 mW/cm²)
Isotropic response ±1 dB
Temperature response +0.8 dB (10°C to 40°C)
CALIBRATION
Calibration frequencies 0.5/ 13.56/ 27.12/ 90 MHz 13.56/ 27.12/ 40.68 MHz
Recommended calibration interval 24 months
