Battery 25.9 VDC, 2500mAH Li-ion battery pack (internal)
Battery life >2hr with RF power continuously on
Battery charger External charger, 29.4 VDC, 1.2 Amp
Analyzer dimensions 14 x 9 x 3.5in (350 x 230 x 90mm)
Case dimensions 22 x 14 x 9in (550 x 350 x 230mm)
Analyzer weight 11lbs (5kg)
Analyzer + case weight 25lbs (11kg)
Operating temperature range 0°C to +45°C
Storage temperature range -10°C to +60°C
Ingress protection (IP) IP54
Relative humidity 5% to 95% RH non-condensing
DESCRIPTION TX FREQUENCY 1 TX FREQUENCY 2 RX FREQUENCY (PIM)
iHA-850A 850MHz 894.0MHz 870.0MHz 846.0MHz
iHA-900A GSM900 960.0MHz 935.05MHz 910.1MHz
iHA-1900A PCS1900 1990.0MHz 1930.0MHz 1870.0MHz
© 2011 Kaelus Inc. All Rights Reserved. Rev2_4.11
www.kaelus.com
|2|
TECHNICAL SPECIFICATIONS CONTINUED |
ELECTRICAL
MECHANICAL
ENVIRONMENTAL
MODELS |
Portable transit case for analyzer and accessories.
WARNING: Use of the portable PIM analyzer in a radiating mode, for
example when connected to an antenna not enclosed in an anechoic
environment, may be a violation of licensing regulations. Users should
have permission in advance, from any licensed operators that might be
affected by these tests. Furthermore, radiating high RF power can pose
a personnel risk.
Specifications subject to change without notice.
