ADVANTAGE
Measurement method Reverse (reflected) PIM, 3rd, 5th, 7th, 9th and 11th order
Residual PIM < -115dBm/-158dBc max (<-125dBm/-168dBc typ) (x2 @ 20W)
User interface ports 3x USB, x1 LAN, 1x RF output (7-16 DIN female), 1x monitor port (N female)
Display 8.4in (213mm) touch screen display
Transmit frequencies See model table
Frequency increment 50 kHz
Frequency accuracy ± 5ppm (max), aging ± 1ppm (max) after first year
Power per tone (adjustable) 2x 2 to 20W (+33 to +43dBm)
Power accuracy (per tone) ± 0.5dB (max)
- Rugged, reliable construction suitable for field use - Fully configurable frequencies, powers and IM products
- Integrated polycarbonate transit case - Simple to operate touch screen interface
- Range to Fault (RTF) enabled - Spectrum monitor, frequency sweep and time trace modes
© 2012 Kaelus. All Rights Reserved.
www.kaelus.com
|1|
iQA Series
Portable Passive Intermodulation Analyzer
Passive Intermodulation (PIM) Analyzer,
Range to Fault (RTF) enabled
TECHNICAL SPECIFICATIONS |
SYSTEM
PRODUCT FEATURES
TRANSMITTER
Receive band (50kHz steps) See model table
Measurement noise floor < -128dBm
Measurement range -50dBm to -128dBm
RECEIVER
The iQA series Passive Intermodulation (PIM) analyzer is a feature rich, high power
PIM test solution. This field proven analyzer enables network operators to improve
site performance by finding and eliminating sources of passive intermodulation at
the cell site. The design includes an integrated panel PC with intuitive touch screen
interface for performing tests and generating site reports.
This version of the iQA ships from the factory enabled to support Range to Fault
(RTF) technology: with the purchase of an optional RTF module, operators are able to
activate RTF mode within the iQA user software to accurately measure the distance
to return loss faults as well as the distance to PIM faults at the cell site.
RTF module sold separately.
