111
Spectrum Analyzers
Pulse quantization error
(PRF > 500/sweep time in pulse measurement mode):
Log; 1.2 dBp-p (RBW
≤
1 MHz)
3 dBp-p (RBW = 3 MHz)
Linear; 4% of reference level (RBW
≤
1 MHz)
12% of reference level (RBW = 3 MHz)
Time Domain Measurement
Amplitude resolution: 12 bits
Sweep time: 50
µ
s to 2 s
Trigger: Free run, single, video, IF detection, external
Hold time: 200 ns to 650 ms
Analog Demodulation
Spectrum demodulation:
Modulation type: AM and FM
Audio output: Internal speaker, earphone jack, adjustable volume
Marker pause time: 100 ms to 1000 s
Digital Modulation Analysis
Applicable modulation system:
π
/4QPSK (PHS, PDC, NADC)
Input range: 10 MHz to 7.5 GHz, at -30 to +30 dBm
Average power: (after calibration, automatic setting)
Measurement accuracy;
(Transient mode)
±
0.8 dB (in PHS, PDC, NADC bands, 15 to 35
°
C)
±
1.0 dB (in PHS, PDC, NADC bands, 0 to 50
°
C)
OBW: Standards measurement possible
ACP:
(Transient (frequency)/CW mode)
Spurious: -20 to -65 dBc
(-70 dBm or more, Transient mode)
Modulation analysis:
GPIB: IEEE-488 bus connector, rear panel
RS232: D-SUB 9 pin, rear panel
P-I/O: D-SUB 25 pin, rear panel
EXT key: DIN, front panel
General Specifications
Temperature: Operating temperature 0 to 50
°
C, 85% RH max.
Power supply: AC 100/220V, switched automatically
Voltage: 100 to 120 V, 220 to 240 V
Power consumption: 300 VA (max.)
Frequency: 50/60 Hz
Weight: 17 kg max. (R3465), 16.5 kg (R3463), (excluding options,
front cover and accessories)
External dimensions: Approx. 177 (H)
×
350 (W)
×
420 (D) mm
(excluding handle, feet and front cover)
Memory card drive: 2 slots, front panel
Connector ; JEIDA Ver. 4.2/PCMCIA 2.1
Digital Modulation Analysis Function Provided Standard
R3465/3463
PHS
0 to -57 dB
(600 kHz offset)
0 to -62 dB
(900 kHz offset)
PDC
0 to -60 dB
(50 kHz offset)
0 to -64 dB
(100 kHz offset)
NADC
0 to -55 dB
(30 kHz offset)
0 to -60 dB
(60 kHz offset)
0 to -60 dB
(90 kHz offset)
(NADC RBW = 1 kHz)
Accessories
Power cable: A01412
Input cable: MC-61
Converter adapter: JUG-201 A/U
Power fuse: 21806.3 (6.3 A)
Options
Option 08 Rx Control Option (for R3560)
Option 09 CDMA Test Source Control Option (for R3561L)
Option 15 Program Loader Option
Option 21
±
5
×
10
-9
/Day X'tal Option
*2
Option 51 GSM Option
*2, *3
Option 52 DECT Option
*2
Option 56 GSM Only Option
*1
,
*2
,
*3
Option 57 DECT Only Option
*1
,
*2
Option 58 GSM/DECT Only Option
*1
,
*2
,
*3
Option 61 CDMA Option
Option 73 FM Deviation Measurement Option
Option 75 Constellation Option (for PDC/PHS/NADC)
Option 76 Graphics Option (for PDC/PHS/NADC)
Option 77 GSM Graphics Option
*2
Option 85 JIS Rack Mount Set
Option 86 EIA Rack Mount Set
*1
: When this option is mounted, functions for measuring PHS, PDC
and NADC standards are not available.
*2
: Option can only be set on R3465.
*3
: GSM option includes GSM, DCS1800, and DCS1900 (PCS1900 in the U.S).
Application Software
PR34650440-IC PHS Auto Test (Tx, manual mode)
PR34650441-IC PHS Remote Test (Tx, remote mode)
PR34650442-IC PHS Auto/Remote Test (Tx, manual/remote)
PR34650450-IC PHS TRx Auto Test (manual mode)
*1
PR34650451-IC PHS TRx Remote Test (remote mode)
*1
PR34650452-IC PHS TRx Auto/Remote Test (manual/remote mode)
*1
PR34650120-IC PDC-MS TRx Auto Test (manual mode)
*1
PR34650121-IC PDC-MS TRx Remote Test (remote mode)
*1
PR34650122-IC PDC-MS TRx Auto/Remote Test
(manual/remote mode)
*1
PR34650710-IC CDMA-BS Tx Auto Test (manual mode)
*2
PR34650711-IC CDMA-BS Tx Remote Test (remote mode)
*2
PR34650712-IC CDMA-BS Tx Auto/Remote Test
(manual/remote mode)
*2
PR34650160-IC PDC-MS Technical Conformance Measurement Software
*3
PR34650460-IC PHS Technical Conformance Measurement Software
(for PS, low power CS)
*3
PR34650470-IC PHS Technical Conformance Measurement Software
(for high power CS)
*3
PR34650770-IC CDMA-BS Technical Conformance Measurement Software
*4
PR32630300-IC GSM/DCS1800-MS Software (manual mode)
*5
PR32630310-IC GSM/DCS1900-BS Software (manual mode)
*5
PR32630500-IC DCS1900-MS Software (manual mode)
*5
PR32630510-IC DCS1900-BS Software (manual mode)
*5
*1
: Requires the R3560 Test Receiver. Earlier versions of the R3465/
3463 firmware may not support this software. Inquire for details.
*2
: Earlier versions of the R3465/3463 firmware may not support this
software. Inquire for details.
*3
: This software is for both manual and remote mode. The software
requires additional measurenent instruments and system
calibration. Inquire for details.
*4
: This software is for manual mode. This software requires
additional measurement instruments and system calibration.
Inquire for details.
*5
: Requires GSM Option. Measurement range is to 3GHz.
This Software can only be set on R3465.
All application software requires the R3465/3463 program loader
(option 15) be installed.
PHS
PDC/NADC
Rang
Accuracy
Frequency error
Reference accuracy
×
carrier frequency ± 5 Hz
Modulation accuracy
0 to 30%
± 1% ± measured value
×
± 2%
± 1 ppm
Transmission measurement
Accuracy
Reference accuracy
×
carrier frequency ± 5 Hz
0 to 30%
± 0.5% ± (measured value)
×
± 2%
± 1 ppm
normal
expand
± 13 kHz
± 100 kHz (± 500 kHz)
± 1.4 kHz
± 5 kHz (± 50 kHz)
Range
Accuracy
( ): Frequency error measurement only in wide mode
