DYNAMIC CHARACTERISTICS Units
CHARGE SENSITIVITY
TYPICAL
pC/g 10.0
MINIMUM pC/g 7.5
FREQUENCY RESPONSE See Typical Amplitude Response
RESONANCE FREQUENCY kHz 45
AMPLITUDE RESPONSE [1]
±5% Hz 1 to 10 000
±1dB Hz .5 to 12 000
TEMPERATURE RESPONSE See Typical Curve
TRANSVERSE SENSITIVITY %
≤
3
AMPLITUDE LINEARITY [2] % 1
Per 400 g, 0 to 2000 g
ELECTRICAL CHARACTERISTICS
OUTPUT POLARITY
Acceleration directed into the base of the unit
produces positive output
RESISTANCE G Ω ≥ 10
ISOLATION M Ω 10
CAPACITANCE pF 900
GROUNDING Signal return is connected to case. Case is
isolated from mounting surface by insulated screw
assembly
ENVIRONMENTAL CHARACTERISTICS
TEMPERATURE RANGE
-67°F to +500°F (-55°C to +260°C)
HUMIDITY Hermetically sealed
SINUSOIDAL VIBRATION LIMIT g pk 1000
SHOCK LIMIT g pk 3000
BASE STRAIN SENSITIVITY equiv. g pk/µ strain 0.02
THERMAL TRANSIENT SENSITIVITY equiv. g pk/°F (/°C) 0.004 (0.007)
PHYSICAL CHARACTERISTICS
DIMENSIONS
See Outline Drawing
WEIGHT gm (oz) 11 (0.39)
CASE MATERIAL Stainless Steel
CONNECTOR Coaxial, 10-32 male thread
MOUNTING TORQUE lbf-in (Nm) 8 (1)
CALIBRATION
SUPPLIED:
FREQUENCY RESPONSE
% 20 Hz to 10 000 Hz
dB 10 kHz to 50 kHz
CHARGE SENSITIVITY pC/g
MAXIMUM TRANSVERSE SENSITIVITY %
CAPACITANCE pF
ENDEVCO
MODEL
2221F
SPECIFICATIONS
The following performance specifications conform to ISA-RP-37.2 (1964) and are typical values, referenced at +75°F (+24°C) and 100 Hz,
unless otherwise noted. Calibration data, traceable to National Institute of Standards and Technology (NIST), is supplied.
ACCESSORIES
Model 3090C-120 (10 ft) CABLE ASSEMBLY
P/N 10207
INSULATED MOUNTING SCREW, 6-32
P/N EHM49 ALLEN WRENCH, 7/64 INCH
Model 2987 ADHESIVE MOUNTING ADAPTER
OPTIONAL ACCESSORIES
Model 2771AM3
IN-LINE CHARGE CONVERTOR FOR
USE WITH CONSTANT CURRENT
SOURCE
Model 2950M3 TRIAXIAL MOUNTING BLOCK
Piezoelectric Accelerometer
NOTES
1. Low-end response of the transducer is a function of its
associated electronics.
2. Short duration shock pulses, such as those generated by metal-
to-metal impacts, may excite transducer resonance and cause
linearity errors. Send for TP290 for more details.
3. Maintain high levels of precision and accuracy using Endevco's
factory calibration services. Call Endevco’s inside sales force at
800-982-6732 for recommended intervals, pricing and turn-
around time for these services as well as for quotations on our
standard products.
Continued product improvement necessitates that Endevco reserve the right to modify these specifications without notice. Endevco maintains a program of
constant surveillance over all products to ensure a high level of reliability. This program includes attention to reliability factors during product design, the support of
stringent Quality Control requirements, and compulsory corrective action procedures. These measures, together with conservative specifications have made the
name Endevco synonymous with reliability.
