MODEL CONFIGURATIONS
Model Number RF Input RF Output Weight Size
500A250B Type N female, front Type N female, front 45.8 kg (101 lb)
50.3 x 34 x 56.9 cm
19.8 x 13.4 x 22.0 in
500A250BM1 Type N female, rear Type N female, rear 45.8 kg (101 lb)
50.3 x 34 x 56.9 cm
19.8 x 13.4 x 22.0 in
500A250BM2 BNC female, rear 7-16 DIN female, rear 45.8 kg (101 lb)
50.3 x 34 x 56.9 cm
19.8 x 13.4 x 22.0 in
500A250BM3 See separate specification sheet.
500A250BM4
Same as 500A250BM2 with enclosure removed for
rack mounting.
35.4 kg (78 lb)
48.3 x 30.5 x 54.4 cm
19.0 x 12.0 x 21.4 in
500A250BM5 Type N female, front 7-16 DIN female, rear 45.8 kg (101 lb)
50.3 x 34 x 56.9 cm
19.8 x 13.4 x 22.0 in
500A250BM6
Same as 500A250BM1 with enclosure removed for
rack mounting.
35.4 kg (78 lb)
48.3 x 30.5 x 54.4 cm
19.0 x 12.0 x 21.4 in
500A250BM7 Type N female, front Type N female, rear 45.8 kg (101 lb)
50.3 x 34 x 56.9 cm
19.8 x 13.4 x 22.0 in
500A250BM8
BNC female, rear Type N female, rear
35.4 kg (78 lb)
48.3 x 30.5 x 54.4 cm
19.0 x 12.0 x 21.4 in Enclosure removed for rack mounting
500A250BM9
Same as 500A250B with enclosure removed for
rack mounting.
35.4 kg (78 lb)
48.3 x 30.5 x 54.4 cm
19.0 x 12.0 x 21.4 in
500A250BM10 See separate specification sheet.
