SPECIFICATIONS
MODEL 500W1000A
RATED POWER OUTPUT ................................................................................... 525 watts minimum
INPUT FOR RATED OUTPUT............................................................................. 1.0 milliwatt maximum
POWER OUTPUT @ 3dB COMPRESSION
Nominal .............................................................................................................. 612 watts
Minimum............................................................................................................. 450 watts
POWER OUTPUT @ 1dB COMPRESSION
Nominal .............................................................................................................. 515 watts
Minimum............................................................................................................. 350 watts
FLATNESS.............................................................................................................
± 2.0 dB maximum
± 0.8 dB with internal leveling
FREQUENCY RESPONSE.................................................................................... 80 - 1000 MHz instantaneously
GAIN (at maximum setting)................................................................................... 57 dB minimum
GAIN ADJUSTMENT (continuous range) ............................................................ 18 dB minimum
INPUT IMPEDANCE............................................................................................ 50 ohms, VSWR 2.0:1 maximum
OUTPUT IMPEDANCE........................................................................................ 50 ohms, VSWR 2.0:1 typical
MISMATCH TOLERANCE* ................................................................................. 100% of rated power without foldback up to 6.0:1 mismatch
above which may limit to 250 watts reflected power.
Will operate without damage or oscillation with any magnitude
and phase of source and load impedance
MODULATION CAPABILITY .............................................................................. Will faithfully reproduce AM, FM, or Pulse modulation
appearing on the input signal.
HARMONIC DISTORTION.................................................................................. Minus 20 dBc maximum at 400 watts
THIRD ORDER INTERCEPT POINT................................................................... 63 dBm typical
RF POWER METER.............................................................................................. 600 watts full scale
PRIMARY POWER (specify) ................................................................................ 200 - 250 VAC, 50/60 Hz, single phase
6500 VA maximum
CONNECTORS
RF Input ....................................................................................................... See Model Configuration
RF Output .................................................................................................... See Model Configuration
External Leveling Inputs .............................................................................. Type BNC female on front panel
Pulse Modulation Input ............................................................................... Type BNC female on front panel
Detected RF Output..................................................................................... Type BNC female on front panel
Safety Interlock ............................................................................................ 15 pin subminiature D on rear panel
Remote Computer Interface ......................................................................... 24 Pin female IEEE-488 (GPIB)
and RS-232 connector on rear panel
Remote Computer Interface (fiberoptic)...................................................... ST Conn Tx and Rx RS-232
COOLING ............................................................................................................. Forced air (self contained fans)See Model Configuration
WEIGHT (approximate)........................................................................................ 174 kg (383 lb)
SIZE (W x H x D)................................................................................................... See Model Configuration
* See Application Note #27
MODEL CONFIGURATION
Model Number
RF Connector Locations & Type
Cooling Air Entry
Size (W x H x D)
Casters
Remarks
500W1000A
Type N female on rear panel
Bottom
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23.0 in
Standard
500W1000AM1
Type N female on rear panel
Front Grills
56.1 x 152.0 x 58.4 cm
22.1 x 60.0 x 23.0 in
Large 5.0"
500W1000AM2
Output Type 7/16 female on rear panel
Input Type N rear panel
Bottom
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23.0 in
Standard
500W1000AM3
Output Type N female on front panel
Input Type N female on rear panel
Bottom
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23.0 in
Standard
500W1000AM4
Type N female on front panel
Bottom
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23.0 in
Standard
500W1000AM5
Input Type N female on front panel. Output Type
C female on front panel.
Bottom
56.1 x 149.9 x 58.4cm
22.1 x 59.0 x 23.0 in
Standard
500W1000AM6
Type N female on rear panel
Bottom
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23in
Standard
Variable input Lockout
500W1000AM7
Type N female on rear panel
Front Grills
56.1 x 149.9 x 58.4 cm
22.1 x 59.0 x 23 in
Standard
